No. Description Qty
189 Tank Fixing Bracket 12
190 Discontinued N/A
191 Discontinued N/A
192 Discontinued N/A
193 Discontinued N/A
194 Discontinued N/A
195 Discontinued N/A
196 Discontinued N/A
197 Discontinued N/A
198 Discontinued N/A
199 Discontinued N/A
200 Discontinued N/A
201 Oil Cup 6×1 2
202 Discontinued N/A
203 Discontinued N/A
204 Discontinued N/A
205 Discontinued N/A
206 Discontinued N/A
207 Discontinued N/A
208 Discontinued N/A
209 Discontinued N/A
210 Discontinued N/A
211 Spindle 2 1
212 Oil Cup 6×1 2
213-1 Spindle 1 1
214 Pipe Clamp 1
215 Discontinued N/A
216 Discontinued N/A
217 Washer Groupware 14 2
218 Discontinued N/A
219 Bolt M8×40 1
220 Pipe Clamp Plate 1
No. Description Qty
221 Washer 20 2
222 Pipe Plug 19×19 2
223 Sponge Gasket 1
224 Washer Groupware 6 1
225 Locating Bush 2
226 Guide Spring 2
227 Plug Screw M18×1.5 2
228 Brake Pulling Plate 1
229 Discontinued N/A
230 Discontinued N/A
231 Screw M8x10 w/glue 4
232-1 High Pressure Hose 2
233 Discontinued N/A
234 Discontinued N/A
235 Gear Shifting Board 1
236 Tension Spring 1
237 Bolt M10×35 1
238 Shifting Lever I 1
239 Shifting Lever II 1
240 Bushing 3
241 Assembling Bracket 1
242 Knob 1
243 Hydraulic Tipping Handle 1
244 Washer 6 1
245 Fitting 2
246 Hydraulic Power Pack 1
247 Coupler 1
248 Shock Absorber 4
249 Key 4.7×12.5 1
250 Bolt M6×10 1
251 Seal FB14×24×7 1
No. Description Qty
157 Washer Groupware 14 2
158 Gear Box Case Paper Spacer 1
159 Output Shaft 2
160 Gear II-1 1
161 Bush 2 1
162 Bush 1 1
163 Key C5×20 2
164 Spline Shaft II 1
165 Discontinued N/A
166 Clutch Fork Shaft ( R) 1
167-1 Gear Box Case ( R) 1
168 Pin 12×20 2
169 Seal FB16×22×4 2
170 Output Gear Bush Paper Spacer 2
171 Gasket 1 4
172 Clutch Spring 2
173 Spring Guide Bush 2
174 Clutch Bush 2
175 Spring Gasket 2
176 Steel Ball 5 70
177 Circlip 58 2
178 Output Gear 1
179 Intermediate Joint Bush 1
180 Intermediate Joint Bush Composite Bushing 2
181 Circlip 26 2
182 Joint Bush 2
183 Spring Gasket 4
184 Circlip 25 2
185 Washer φ8 10
186 Output Gear Bush Weldment 2
187 Seal FB42×25×7 2
188 Bolt M6×60 4
25
YD8105PM04 - 1804
|
Parts List
