PARTS LIST
No. Description
Qty
83
φ47 Axle Head Cover (Support Wheel)
4
84
Track 180×60 2
85
Two-head Stud 4
86
Guard Plate (L) 1
87
Screw M8×20 4
88
Nut M16 2
89
Bolt M16×140 2
90-1
Chassis Weldment 1
91
Optical Axis 1
92
Cotter Pin
∮
4X35 5
93
Rear Cover 1
94-1
Guide Wheel Axle 1
95
Gasket 42×30×7 2
96
Circlip 42 4
97
Bearing 61905-2RS 4
98
Guide Wheel 2
99
φ47 Axle Head Cover (Guide Wheel)
2
100
Guard Plate (R) 1
101
Supporting Bracket Weldment 1
102
Large Belt Pulley Cover 1
103
Bolt M6×20 1
104-1
Dumper Box 1
105
Spring Washer 2
106
Discontinued N/A
107
Screw M5×20 2
108
Nut M5 2
109
Guard Cover 1
110
Cylindrical Pin 5×30 1
111
Discontinued N/A
112
Cylindrical Pin 3×30 1
113-1
Locating Nut 1
114
Washer Groupware 20 1
115
O-ring 11.2×1.8 1
116-1
Lever Mount Bracket 1
117
Seal FB17×40×7 2
118
Spline Shaft I 1
119-1
Duplex Slip Gear 1
No. Description
Qty
120-1
Gear 1
121
Bearing 6302 1
122
Gearshift Fork Guide Pin 1
123
Small spring 1
124
Steel Ball 6 1
125
Gearshift Fork 1
126-1
Rivet Assembly 1
127
Brake Disk Assy 1
128
Discontinued N/A
129
Discontinued N/A
130
Discontinued N/A
131
Circlip 12 1
132
washer 6 4
133
Bolt M6×16 4
134
Expansion Brake Cover 1
135-1
Stud 1
136
Vent-Plug Joint sleeve 1
137
Vent-Plug 1
138
Screw M8×30 3
139-1
Bolt M6×30 3
140
Screw M8×130 6
141
Clutch Fork Shaft ( L) 1
142
Bolt M6×20 3
143
Swing Plate 2
144
Gear III-4 1
145
Gear III-3 1
146
Large Belt Pulley 1
147
Bearing 6303 5
148
Gear II-5 1
149
Gear II-4 1
150
Gear II-3 1
151
Gear II-2 1
152
Gear III-2 Bush 1
153
Gear III-2 1
154
Gear Shaft III 1
155-2
Gear Box Case (L) 1
156
Plug M14×1.5 2
No. Description
Qty
46
Brake Cable 1
47
Bolt 5/16-24×20 4
48
Screw M10×70 1
49
Lever 1
50-1
Gear Box Complete 1
51
Lock Nut M10 2
52
Driving Wheel 2
53
Screw M10×60 1
54
Small Belt Pulley Cover 2 1
55
Discontinued N/A
56
Screw M6×8 w/glue 1
57
Screw M5×12 1
58
Circlip 35 2
59
Circlip 15 1
60
Bearing 6202-2RS 2
61
Tensioner Pulley 2
62
Discontinued N/A
63
Wheel Shaft Press Plate 1
64-1
Belt Plate 4
65
Discontinued N/A
66
Discontinued N/A
67
Support Plate 1
68
Bolt M8×50 2
69
Washer 2
70
Bolt M8×45 2
71
Cable Fixing Bracket 1
72
Rubber Mat 4
73
Bolt M10×65 w/glue 8
74
Nut M8 4
75
Support Plate (L) 1
76
Long Extension Sping 1
77
Gasket 25×47×7 8
78
Bearing 6204-2RS 16
79
Engine(6.5HP) 1
80
Supporting Wheel weldment 8
81
Washer φ10 14
82
Bolt M10×25 8
24
Power Trackbarrow
»
Operator’s Manual
YD8105PM04 - 1804
Parts List
|
