YARDMAX YS0552 - Introduction; Discover the YARDMAX Advantage; Model and Serial Numbers; Record Identification Numbers

Introduction 1
Specications 2
Symbols 3
Safety 3
Contents Supplied 5
Know Your Machine 5
Assembly 6
Operation 7
Freeing a Jammed Log 9
Replacing Hydraulic Oil 10
Sharpening the Wedge 10
Troubleshooting 11
Wiring Diagram 11
Plumbing Diagram 11
Parts Diagram 12
Parts List 13
TABLE OF CONTENTS
Your new YARDMAX™ electric log splitter offers quality
construction, and is easy and safe to operate. With
proper use and care, it is designed to give you many years
of dependable service.
Prepare to experience the durability to take on any job
— with the ease, portability, and convenience of clean,
electric splitting!
Discover the YARDMAX Advantage
At YARDMAX, we understand that land ownership
definitely has its privileges, but it also comes with a
great deal of responsibility. When duty calls and you
need to respond, will you have what it takes to tame the
great outdoors?
When looking for outdoor power equipment (OPE) to get
the job done right, at the right price, YARDMAX delivers
the perfect combination of performance and practicality.
YARDMAX has a solution that’s right for you.
Your new
Log Splitter
will more than satisfy your
expectations. It has been manufactured under stringent
quality standards to meet superior performance criteria.
You will nd it easy and safe to operate, and with proper
care, it will give you many years of dependable service.
MAX Performance, MAX Value, MAX Support —
that’s YARDMAX
Backed by decades of proven manufacturing expertise
Enhanced design features come standard
Engineered for the best user experience
Quality metal parts are used instead of plastic
A robust warranty supports all products
Budget-friendly prices make it practical
Up for the job? YARDMAX is.
√
√
√
√
√
√
Carefully read through this entire operator’s manual
before using your new Log Splitter. Pay attention to
all cautions and warnings.
MODEL AND SERIAL NUMBERS
Record the model and serial number as well as date
and place of purchase for future reference. Have this
information available when ordering parts or optional
accessories and when making technical or warranty
inquiries.
DISCLAIMER
YARDMAX reserves the right to discontinue, change,
and improve its products at any time without notice
or obligation to the purchaser. The descriptions and
specications contained in this manual were in effect at
printing. Equipment described within this manual may be
optional. Some illustrations may not be applicable to your
unit.
ENVIRONMENTAL
Recycle unwanted materials instead of disposing of
them as waste. All tools, hoses, and packaging should
be resorted, taken to the local recycling center and
disposed of in an environmentally safe way.
Hydraulic Log Splitter
YS0552
5 ton
20 1/2” long,
10” diameter
120V~ 60Hz,
15A, 1 3/4HP
108 lbs
Manufacture Date:
11~201~10
2015 2016 2017
1 2 3 4 5 6
7 8 9 10 11 12
21~30
Force:
Log Capacity:
Motor:
Weight:
Made in P.R.C
100010616
Model Number
Serial Number
SUPPORT
Have questions about your YARDMAX equipment?
Call us at 844-YARDMAX, email us at
support@yardmax.com, or contact us via your
favorite social media site.
1 2
Electric Log Splitter
»
Operator’s Manual
Specications
||
Introduction
