No. Description QTY.
61 Gear Housing Plate 1
62 Circlip 10 2
63 Gear Shaft 1
64 Steel Ball 2.5 1
65 Gear 2
66 Pin 2.5x4 1
67 Flat Washer 5 6
68 Bolt M5x185 3
69 Motor Cover 1
70 Oil Seal FB11x26x7 1
71 Nut M8 1
72 Screw M8x35 1
73 Motor 1
74 Fan 1
75 Circlip 17 1
76 Shroud 1
77 Flat Washer 5 6
78 Spring Washer 5 6
79 Screw M5x10 2
80 Bolt M8x16 4
81 Nut M8 8
82 Cable & Plug 1
83 Strain Relief 1
84 Screw M4x10 11
85 Switch Box Cover 1
86 Airproof Underlay 1
87 Connection Terminal 1
88 Switch 1
89 Capacitor 1
90 Switch Box 1
No. Description QTY.
91 Waterproof Underlay 1
92 Motor Support Left Shoe 1
93 Motor Support Right Shoe 1
94 Pin 8x24 2
95 O-Ring 46.2x1.8 2
96 Sliding Sleeve 4
97 Bolt M8x30 3
98 Rear Support Stand 2
99 Rear U-Shaped Connecting Pipe 1
100 Front Support Stand - Left 1
101
Front U-Shaped Connecting Pipe
1
102 Front Support Stand - Right 1
103 Bolt M8x50 2
104 Screw ST2.9X6.5 2
105 Guard board 1
106 Lock Nut M14 2
107 Flat Wahser 14 2
108 Nut M14 2
109 Log Pusher Connection Weldment 1
110 Plastic Insert - Lower 1
111 Plastic Insert - Upper 1
112 Log Pusher 1
113 Lock Nut M10 4
114 Flat Wahser 10 5
115 Screw M10x25 4
116 Screw M8x85 2
117 Screw M8x100 2
118 Support Bracket 2
119 Log Tray Table 1
120 Ring-shaped Nut 1
121 Handwheel 1
No. Description QTY.
1 Lever Mount Nut 1
2 Cap Nut M10 3
3 Lever 1
4 Nut M8 1
5 Lever Guard 1
6 Customized Nut 2
7 Copper Gasket 10 4
8 Safty Valve Bolt M8 1
9 O-Ring 5.5x2 1
10 Snap Washer 6 1
11 Valve Retract Spring 1
12 O-Ring 6x1.5 1
13 Valve Core Rod 1
14 Sliding Pressure Sensor Sleeve 1
15 Sliding Pressure Sensor Sleeve Spring 1
16 Alumium Cover- Rear 1
17 O-Ring 50x2.65 1
18 Piston 1
19 Piston Ring 55 1
20 O-Ring 32x3.5 1
21 Spring 1
22 Stud Bolt 4
23 Hydraulic Cylinder 1
24 Alumium Cover-Front 1
25 Piston Rod Seal 30 1
26 O-Ring 7x1.9 1
27 Knurled Screw 1
28 Wahser Groupware 14 1
29 Dipstick 1
30 Piston Rod 1
No. Description QTY.
31 Frame Tube 1
32 Lead Plank 1 - Left 1
33 Lead Plank 2 - Right 1
34 Washer 6 4
35 Screw M6x10 4
36 Lever Knob 1
37 Support Frame - Right 1
38 Drain Plug 1
39 Washer Groupware 16 1
40 Valve Sleeve 1
41 O-Ring 10x2 5
42 Adjusting Screw M5x8 1
43 Steel Ball 6 1
44 Safty Valve Spring 1
45 Adjusting Screw M8x8 1
46 Support Frame - Left 1
47 Arc Washer 30 18
48 Screw M8x45 12
49 Nut M8 12
50
Support Stand Mounting Bracket - Right
1
51 Wheel Cap 2
52 Support Stand Mounting Bracket - Left 1
53 Wheel 2
54 Circlip 14 2
55 Wheel Axle 2
56 Bolt M8x55 6
57 Spring Washer 8 9
58 Washer 8 9
59 Gear Pump Cover 1
60 O-Ring 10.6x2.65 2
PARTS LIST
15 16
Electric Log Splitter
»
Operator’s Manual
Parts List
||
