YARDMAX YS0952 - Page 16

YS0952PM00 - 2002
No. Description QTY.
61 Wheel Cover A 2
62 Wheel Shaft Snap Ring A 16 2
63 Wheel A 2
64 Wheel Shaft Frame 1
65 Nut M8 5
66 Nut M10 4
67 Hex. Bolt M8x35 1
68 Log Pusher 1
69 Washer 6 4
70 Cross Headed Screw M6x12 4
71 Body Cover - Left 1
72 Hex. Bolt M10x30 4
73 Plastic Insert - Upper 1
74 Plastic Insert - Lower 1
75 Drawing Weldment 1
76 Support Leg 1
77 Thin Nut M16 2
78 Spring Washer 16 2
79 O-Ring 10.6x2.65 2
80 O-Ring 46.2x1.8 2
81 Gear Shaft Snap Washer 10 2
82 Steel Ball 2.5 1
83 Bolt 8.8 M8x55 6
84 Spring Washer 8 9
85 Bolt 8.8 M8x30 3
86 Pump Cover 1
87 Sleeve Bearing 4
88 Gear Shaft 1
89 Pin 2.5x4 1
90 Gear 2
No. Description QTY.
91 Pin 8x24 2
92 Gear Housing Plate 1
93 Motor Support Shoe - Right 1
94 Motor Cover 1
95 Motor Support Shoe - Left 1
96 Seal FB11x26x7 1
97 Motor Assembly 1
15
|
Parts List
