KNOW YOUR MACHINE
FEATURES AND CONTROLS
Switch Box
Switch
Motor
Wheels for Minor Moving ONLY
Control Lever Guard
Hydraulic Control Lever
Log Retaining Plates
Log Pusher
Work Table
Support Leg
Bleed Screw
Wedge
Lift Handle
Oil Drain Bolt w/ Dipstick
BLEED SCREW
Failure to loosen the bleed screw will keep the
sealed air in the hydraulic system compressed.
Continuous air compression and decompression
will blow out the seals of the hydraulic system and
cause permanent damage to the log splitter.
Before operating your log splitter, loosen the bleed
screw enough to allow air to freely ow in and out of
the oil tank.
Air flow through the bleed screw hole should be
detectable when the log splitter is in use.
Before moving the log splitter, make sure the bleed
screw is tightened to avoid oil leakage.
