YS0952PM00 - 2002
No. Description QTY.
1 Nut 4
2 Snap Washer 22 1
3 Washer 10x2 1
4 Valve Rod 1
5 O-Ring 8.75x1.8 1
6 Safety Valve Spring basis 1
7 O-Ring 11.2x2.65 3
8 Safety Valve Spring 1
9 Safety Valve 1
10 Cylinder Cover - Left 1
11 Safety Valve 1
12 O-Ring 10.6x1.8 2
13 Safety Valve Core Adjusting Spring 1
14 Adjusting Spring Basis 1
15 Stud 4
16 Cylinder 1
17 Piston 1
18 Piston Ring 70 1
19 O-Ring 35.5x3.55 1
20 Restoring Spring 1
21 Circlip 40 1
22 Snap Washer 1
23 O-ring 38.7x2.65 1
24 O-ring 64.4x3.1 2
25 O-ring 7x1.9 1
26 Bleed Screw M5x12 1
27 Wear-resisting Belt 127x4x2 1
28 O-Ring 40 1
29 Piston Seal 40 1
30 Piston Rod Weldment 1
No. Description QTY.
31 Hex. Bolt M8x20 2
32 Moving Handle 1
33 Washer 16 2
34 Nut M16 2
35 Copper Washer 12 4
36 Safety Valve 1
37 O-Ring 17x1.8 5
38 Screw M10x8 2
39 Steel Ball 8.5 1
40 Valve Rod Restoring Spring 1
41 O-Ring 16x2.65 1
42 Valve Base 1
43 Intake Hose 1
44 Connection Hose 1
45 Cylinder Cover Guard 1
46 Lever Nut 1
47 Lever Head 1
48 Lever 1
49 Carriage Nut M10 3
50
Seperating Plate
1
51 Bolt M8x16 12
52 Washer 21
53 Body Cover - Right 1
54 Tube Frame 1
55 Cylinder Cover - Right 1
56 Dipstick Washer 14 1
57 Dipstick 1
58 Guard Cover - Right 1
59 Guard Cover - Left 1
60 O-Ring 10.6x2.65 2
PARTS LIST
14
Electric Log Splitter
»
Operator’s Manual
Parts List
|
