Operation
TO MANUALLY WIND LINE (SEE FIG L1-L3)
Important! Your trimmer is designed to use only line with a maximum diameter of 1.65 mm.
Take approximately 3 m of line. Insert 15mm of line into the spool holes and wind line in the
direction of the arrows on the top of the spool (See Fig. L1, L2). Leave approximately 100 mm
of line unwound and place it into the cleat. Care should be taken to ensure that the line is neatly
coiled on the spool. (See Fig. L3) Failure to do so will impair the efciency of the automatic line
feed. Then t the spool as described above in “To changing the Spool”.
L1
L3
L2
