Yardworks 270-3397 - Component Identification Diagram

8
29
28
7
8
11
12
25
27
13
10
26
14
16
17
18
24
15
22
20
19
23
21
1
1. Handlebar 16. Hex key wrench
2. ON/OFF trigger 17. Charger plug
3. Crank chute handle 18. 20V lithium-ion dual-port charger
4. Upper handle frame 19. 20V 4.0 ah lithium-ion Batteries (2)
5. Crank rod retainer 20. Push button for battery indicator
6. Middle handle frame 21. Battery indicator
7. Handle frame latch +
thread connector sets (4) 22. Push lock button
8. Chute deflector handle 23. Scraper bar
9. Crank rod 24. Wheels (2)
10. Lower handle frame 25. Auxiliary handle
11. Chute deflector 26. Battery compartment
12. Chute deflector trigger 27. Cable clips (2)
13. Discharge chute 28. Switch box
14. LED lights (2) 29. Safety lock button
15. Auger blades
