Know Your Lawn Tractor
Figure 4-1
A Speed Control Lever/ Parking Brake E Throttle Control Lever
B Clutch-Brake Pedal F Ignition Switch Module
C Shift Lever G Deck Lift Lever
D Choke Control† H PTO (Blade Engage) Lever
NOTE: Any reference in this manual to the RIGHT or LEFT side of the tractor is observed from operator’s position.
† If so equipped
NOTE: Any reference
in this manual to the
RIGHT or LEFT side of
the tractor is observed
from operator’s position.
NOTE: Steering wheel not shown for clarity
For shipping reasons,
seats are either
fastened to the tractor
seat’s pivot bracket
with a plastic tie, or
mounted backward to
the pivot bracket. In
either case, free the
seat form its shipping
position and remove
the two hex screws
(or knobs, on models
so equipped) from the
bottom of seat before
proceeding with ap-
plicable instructions.
