Inverter SIO Driver
GP-Pro EX Device/PLC Connection Manual
40
î External Device Settings
To configure communication settings, use the ENTER, Up, Down, or Shift/RESET key on the digital operator
located on the front of the inverter. Refer to your External Device manual for details.
1 Press the Up key to display [STUP].
2 Press the ENTER key.
3 Press the Up key to display the parameter you want to set.
4 Press the ENTER key.
5 Press the Up, Down, or Shift/RESET key to display the setting value.
6 Press the ENTER key.
7 Reboot the External Device.
This completes the setting of the External Device.
Parameter No. Settings Setup Description
b1-01 2 Frequency Reference Selection 1
b1-02 2 Run Command Selection 1
H5-01 01 Node Address Setting (HEX)
H5-02 3 Communication Speed Selection
H5-03 1 Communication Parity Selection
H5-04 3 Stopping Method After Communication Error
H5-05 1 Communication Fault Detection Selection
H5-06 5 Drive Transmit Wait Time
H5-07 1 RTS Control Selection
H5-09 2.0 CE Detection Time
