OPERATIONS
2. Continuous Draining
You can connect a drain pipe to the
continuous drain port to
continuously drain the water from
the water tank.
(Note: The continuous drain port
diameter is 0.63inch.)
Continuous Drain
Water Tank
3. Continuous Drain Pipe Installation
● The drain pipe arches upward at point D
higher than point B. Air and water are prone
to appear in the water pipe, which makes the
water unable to be drained out smoothly
through the pipe.
Picture 1: Example of improper installation.
Picture 2: Example of improper installation.
● The contacting point D between the drain
pipe and the container is lower than the
continuous drain port A, but higher than the
lowest point B of the pipe. Air and water are
prone to appear in the water pipe, which makes
the water unable to be drained out smoothly
through the pipe.
● The water outlet C of the drain pipe should
not be inserted into the water.
Picture 3: Example of proper installation.
● The water passes through the continuous
drain outlet A all the way to point B and point C.
You can use a container to collect the water or
drain it into the sewer. (The outlet C should be
lower than the continuous drain outlet A at
least 3.97 inches, and it is not recommended
to extend the original drain pipe).
