YCF 50E - Standard Torque Values; Fastener Torque Specifications

2016
86
English
STANDARD TORQUES VALUES
FASTENER TYPE
TORQUE
Nm (kgf-m)
FASTENER TYPE
TORQUE
Nm (kgf-m)
5 mm hex bolt and nut, pan
head screw #6,
4,9 (0.5)
5 mm pan-head screw
3,9 (0,4)
6 mm hex bolt and nut, pan
head screw #6,
9,8 (1.00)
6 mm pan-head screw
8,8 (0,9)
8 mm hex bolt and nut, pan
head screw #6,
22 (2.2)
6 mm flange bolt (8 mm head, small flange)
8,8 (0,9)
10 mm hex bolt and nut, pan
head screw #6,
34 (3.5)
6 mm flange bolt (10 mm head) and nut
12 (1,2)
12 mm hex bolt and nut, pan
head screw #6,
54 (5.5)
8 mm flange blot and nut
10 mm flange bolt and nut
26 (2,7)
39 (4,0)
