YCF 50E - Wheel, Suspension, and Steering Specifications; Front Wheel;Suspension;Steering Torque Specs; Rear Wheel;Suspension;Brake Torque Specs

2016
87
English
FRONT WHEEL/SUSPENSION/STEERING SPECIFICATIONS
ITEM
QTY
Thread Dia. (mm)
TORQUE Nm (kgf-m)
Engine stop switch hold-down screw
2
4
2 (0,2)
Handlebar clamp top stem face bolt
4
6
9,8 (1,0)
Handlebar clamp bottom stem face bolt
2
10
47 (4,8)
Lower fork shear pin
2
8
32 (3,3)
Brake lever adjustment screw
1
6
2,9 (0,3)
Brake lever adjusting nut
1
6
5,9 (0,6)
Spoke
36
BC 2,9
2,9 (0,3)
Front wheel axle nut
1
15
59 (6,0)
Front brake lever screw
1
6
9,8 (1,0)
Fork bolt
2
10
23 (2,3)
Front fork top nut
2
20
23 (2,3)
Fork socket-head screw
2
8
20 (2,0)
Steering column nut
1
22
74 (7,5)
Steering column upper thread
1
22
voir p.12-28
Throttle valve housing bolt
1
5
3,9 (0,4)
REAR WHEEL/SUSPENSION BRAKE SPECIFICATIONS
ITEM
QTY
Thread Dia. (mm)
TORQUE Nm (kgf-m)
Spoke
36
BC 2,9
2,9 (0,3)
Rear wheel axle bolt & nut
1
15
59 (6,0)
Drive sprocket nut
4
8
32 (3,3)
Rear suspension arm brake nut
1
6
9,8 (1,0)
Swingarm pivot nut
1
10
39 (4,0)
Rear shock absorber bolt & nut
2
10
34 (4,5)
