Yealink SIP-T27G Manual

Using Enhanced DSS Keys on Yealink IP Phones
3
Macro Action
Description
$T<type>$
The embedded action type. Multiple actions can be
defined. Supported action types include:
 invite
 dtmf
 refer
 intercom (not applicable to CP860 IP phones)
Example: *338$Tdtmf$ defines sending the *338 by the
type of dtmf.
Note: We recommend that you always define this field.
If it is not defined, the supplied digits are dialed using
INVITE.
$M<macro>$
The embedded macro. The <macro> string must begin
with a letter. If the macro name is not defined, the
execution of the action string will be ignored.
Example: $MAA$ means invoking the EDK macro AA.
$S<softkey ID>$
The functionality of performing this action is the same
as that of pressing the desired soft key.
Each soft key has a unique identifier on the IP phone,
you can configure this parameter according to the
system-defined softkey ID. If the softkey ID is not
defined on the phone or there is no matched soft key on
the current screen, the execution of the action string will
be ignored. The softkey ID is case-insensitive.
Example: $Sanswer$ means pressing the Answer soft
key.
Yealink IP phones support customizing soft keys. When
invoking a custom soft key, the prefix “#” must be
added.
Example: If the custom softkey label is IVR1, the custom
softkey ID is custom_macro, then
$S#custom_macro$ means pressing the IVR1 soft key.
Note: To view the softkey ID, you can configure the
value of the parameter “edk.id_mode.enable” to 1
(Enabled) and then long press the Volume Up key when
the phone is idle. For more information, refer to
Configuring EDK ID Mode.
$K<key name>$
The functionality of performing this action is the same
as that of pressing the desired hard key.

Yealink SIP-T27G Specifications

General

Mounting	Desk/Wall
Handset type	Wired handset
Product type	IP Phone
Product color	Black, Gold
Wall mountable	Yes
Display diagonal	3.66 \
Display resolution	240 x 120 pixels
RJ-9 ports quantity	2
USB 2.0 ports quantity	1
Voice codecs	CNG, G.711, G.722, G.723.1, G.726, G.729, G.729ab, VAD, iLBC
Dual-Tone Multi-Frequency (DTMF) modes	SIP info
Lines quantity	8 lines
Phonebook capacity	1000 entries
Number of VoIP accounts	6
Bluetooth	-
Security algorithms	AES, MD5
Networking standards	IEEE 802.1Q, IEEE 802.1p, IEEE 802.1x, IEEE 802.3af
Ethernet LAN interface type	Gigabit Ethernet
Volume control	Digital
Operating temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	10 - 95 %
Cables included	LAN (RJ-45)
Number of handles included	1 pc(s)
Harmonized System (HS) code	85171800

Weight and Dimensions

Depth	210 mm
Width	265 mm
Height	170.5 mm
