Yealink SIP-T32G User Manual

User Guide SIP-T32G IP Phone
14
You can view the system status of your phone via phone user interface or web user
interface.
Available information of phone status includes:
 Network status including WAN port and LAN port information.
 Phone status including device model, firmware version and MAC address.
 Account status indicating the register status of sip accounts.
To view the phone status via phone user interface:
1. Press , or press Menu->Status.
2. Press or to scroll through the list and view the specific information.
To view the phone status via web user interface:
1. Open the web browser of your computer.
2. Enter the IP address in the browser’s address bar, and then click Enter.
3. Enter the User Name (admin) and Password (admin) in the pop-up dialogue box.
4. Click OK to login.
If your phone cannot contact a DHCP server for any reason, you need to configure a
static IP address manually.
To configure a static IP address via phone user interface:
1. Press Menu->Setting->Advanced Settings (password: admin) ->Network->WAN
Port->Static IP Client.

Yealink SIP-T32G Specifications

General

Keypad number of keys	32
Speakerphone	Yes
Voice codecs	G.711, G.722, G.723.1, G.726
Mounting	Desk/Wall
Handset type	Wired handset
Product type	IP Phone
Product color	Black
Touchscreen	-
Display resolution	400 x 240 pixels
Display number of colors	262144 colors
Lines quantity	- lines
Phonebook capacity	1000 entries
Number of VoIP accounts	3
Bluetooth	No
Security algorithms	802.1x RADIUS, HTTPS, SSL/TLS
Ethernet LAN (RJ-45) ports	2
AC adapter input voltage	100 - 240 V
AC adapter output voltage	5 V
Power consumption (typical)	4 W
Operating relative humidity (H-H)	10 - 95 %
Compliance industry standards	IEEE 802.3af
Number of handles included	1 pc(s)

Weight and Dimensions

Depth	200 mm
Width	185 mm
Height	90 mm
Weight	770 g
