Yealink SIP-T53W User Guide

Phone user guide – Yealink SIP-T53W
9312 Interline Ave. Baton Rouge LA 70809 (225) 924-2700 pdvn.net
Call Park
Call Park is an enhanced hold feature that will allow you to place a call on hold that can be retrieved from any
phone on the system.
To place a call into a park orbit: Ask the caller to hold. Press an available Park orbit buon on your phone – Park 1,
Park 2 etc. That park buon will light in red on every phone on the system.
To retrieve a parked call, press the same park orbit buon. The call informaon will show on the display. If the call
is not retrieved, it will ring back to the phone that originally placed it on Park.
Voice Mail Set Up and Use
To set up your mailbox, press to go to voice mail. For the inial setup – you will be prompted to enter your
new password, then #. You will be prompted to reenter your password, then #. Then you will be prompted to
record a greeng.
Once your mailbox is set up, you will receive nocaons on your screen if you have new messages. Press the
Connect so key to access your messages. Or you can press the buon on your phone. You will hear how
many messages you have. Press 1 to listen to your messages. When listening to messages, you can press 1 to save
or 7 to delete. You can also press 3 to forward a message to another mailbox on the system.
To update password, greeng, or name in mailbox: Press 5 to manage your mailbox.
To change greeng press 1. To change name, press 2. To change password, press 3.
Your system may be enabled with the voice mail to email feature. If so, voice mails will come to your email as a
.wav le and can be shared via email.
TIP: If you need a voice mail password reset, submit a service request.

Yealink SIP-T53W Specifications

General

Mounting	Desk/Wall
Handset type	Wired handset
Product type	IP mobile phone
Product color	Gray
Keypad illumination	Yes
Wi-Fi standards	802.11a, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	4.2
Security algorithms	AES, HTTPS, SIPS
Networking standards	IEEE 802.1p, IEEE 802.1x, IEEE 802.3af
Ethernet LAN interface type	Gigabit Ethernet
Supported network protocols	FTP/TFTP/HTTP/HTTPS
Dual-Tone Multi-Frequency (DTMF) modes	In-band, Out-of band, SIP info
USB 2.0 ports quantity	1
Ethernet LAN (RJ-45) ports	2
Lines quantity	8 lines
Phonebook capacity	1000 entries
Number of VoIP accounts	12
AC adapter input voltage	100 - 240 V
AC adapter output current	1.2 A
AC adapter output voltage	5 V
Power consumption (typical)	2.3 W
Volume control	Buttons
Number of programmable keys	8
Storage temperature (T-T)	-30 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 95 %
Display diagonal	3.7 \
Display resolution	360 x 160 pixels
Cables included	LAN (RJ-45)
Number of handles included	1 pc(s)
Number of DECT wireless handsets	4
Voice codecs	G.722, G.723.1, G.726, G.729A, G.729B, OPUS, iLBC

Weight and Dimensions

Depth	210.6 mm
Width	212 mm
Height	174.5 mm
