This document is an owner's manual for the Yeti SB130/LR bicycle, providing comprehensive information for its setup, maintenance, and safe operation. It emphasizes the importance of proper care to ensure the bicycle's performance and longevity, while also highlighting the advanced design and features of Yeti bikes.

The manual begins with a congratulatory message to the owner, underscoring the high value, performance, and ride quality expected from a new Yeti bicycle. It states that each frameset and component is custom-specified and designed to enhance the riding experience, promising endless hours of two-wheeled fun for both beginner and seasoned cyclists. The document clarifies that this model-specific manual should be used in conjunction with the general Yeti Owner's Manual and any manuals supplied by suspension manufacturers. It advises users to download these materials from the internet or contact their local dealer if they were not received.

A crucial aspect highlighted is the hazardous nature of bicycling, even under optimal conditions. The manual stresses that proper maintenance is the rider's responsibility and, when done correctly, helps reduce the risk of injury and damage to the bicycle. It outlines basic setup and maintenance recommendations, but due to the impossibility of anticipating every situation during assembly, setup, and maintenance, Yeti strongly recommends that all service and repairs be performed by an authorized Yeti Dealer. The document contains numerous "Warnings" and "Cautions" to inform users about potentially hazardous situations that could lead to serious injury, death, or minor injuries and damage to the bicycle or its components. It is critical for users to read and understand all warnings and cautions. The manual also notes that technological advances have made bicycles and components more complex, and the pace of innovation is increasing, making it impossible for the manual to provide all necessary information for proper repair and maintenance. Therefore, having work performed by an authorized Yeti retailer is deemed critical to minimize injury risks.

The "Lowdown on the SB130/LR and Its Features" section details the key attributes of the bicycle:

Switch Infinity Technology: The SB130 delivers 130 mm (137mm for SB130 LR) of travel with Yeti's patented Switch Infinity Technology, ensuring efficient pedaling performance while maintaining smooth and continuous operation on rough terrain.
High Modulus Carbon Fiber: The frame is constructed from high modulus carbon, providing a stiff, strong, and lightweight chassis.
Colleted Pivot Axle System: This system creates a stiff interface between the front and rear triangles of the frame, reducing bearing wear. Custom Enduro Max sealed bearings ensure free movement at the pivots.
Optimized for 1x Drivetrains: The SB130/LR eliminates the front derailleur mount, making it a 1x drive-specific frame, which increases overall frame stiffness.
ISCG 05 Chainguide Mounts: These mounts are included for riders who desire extra drivetrain security in challenging sections.
Integrated Head Tube: The integrated head tube (41mm/52mm) design allows for a larger head tube with more area, increased stiffness, and a lower overall ride height without compromising performance.
Suspension by FOX: The SB130 uses a 210 x 52.5mm Float X shock, while the SB130 LR uses a 210 x 55mm Float X shock, both from Fox Racing Shox.
Custom Debris and Chain Slap Guards: Custom guards on the seat stay, chain stay, and down tube keep the bike quiet during rides and protect the frame from damage.
Internal Cable Routing: All cables are routed internally, contributing to a quiet and clean aesthetic, and reducing cable rub on the paint.
Integrated Axle and Derailleur Hanger System: The bike features dedicated 12 x 148 Boost dropouts and an integrated hanger with axle threads for enhanced strength, stiffness, and ease of hanger and wheel installation.

The manual also includes detailed geometry tables for both FOX 36/150MM FORK and FOX 36/160MM FORK configurations, providing measurements for various frame sizes (Small, Medium, Large, X-Large). These tables list dimensions such as seat tube length, effective top tube length, head tube angle, effective seat tube angle, chainstay length, wheelbase, estimated BB height, standover, head tube length, axle to crown, fork offset, stack, reach, front center, and vertical fork travel. A "FIT" guide helps riders choose the appropriate frame size based on their height.

A significant section is dedicated to "Keep Your Yeti Fresh and Clean," which includes an overview of maintenance guidelines. It emphasizes that following these guidelines helps maintain performance and prevent serious problems. Service intervals can vary based on climate, trail conditions, and riding frequency. If unsure about performing maintenance, users are advised to contact an authorized Yeti Dealer. A detailed maintenance schedule is provided, categorizing tasks as weekly, monthly, 3 months, or annually. These tasks include cleaning and lubing the chain, checking tire and shock pressure, cleaning the bike, checking brake function, inspecting for loose bolts, checking and tightening the headset, thoroughly cleaning pivot points, lubricating the Infinity Link, checking/replacing brake pads, inspecting tires for wear, checking spoke tension, checking chain for wear, and a complete tune-up by an authorized Yeti Dealer.

The manual provides a "Key Torque Specs" table, listing part numbers, descriptions, and recommended torque values (in Nm) for various components, such as the main pivot axle, SS pivot bolt, collet axle, collet wedge bolt, link pivot hardware, derailleur hanger, and switch link mount. Yeti strongly recommends using a torque wrench for assembly and refers to step-by-step assembly instructions for specific torque settings.

"Seat Post Routing" offers detailed instructions for both "Standard Setup" and "Park Tool Setup." For standard setup, it describes removing the lower cable port access cover, installing the seatpost housing into the head tube port, pushing it through the frame and up into the seat tube, and finally out the seat tube access port. The Park Tool Setup involves using a Park Tool Router tool to guide the housing. The section also includes instructions for "Hydraulic Setups," detailing how to route shifter housing and connect it to the seatpost housing with a double-barb, and how to route the brake line.

"Switch Infinity Service" provides step-by-step instructions for maintaining the Switch Infinity link. This includes removing the main pivot collet wedge bolt and collet axle, cleaning the link, applying new grease to the grease ports using a needle-type grease gun, wiping off excess grease, and reinstalling the main pivot collet bolt and collet wedge. Specific torque values are provided for these steps.

The "Frame Assembly" section is a comprehensive guide for assembling the bicycle frame. It starts with "Yeti Tips" on using good condition tools and prepping bolt threads with Loctite or grease. A list of "Tools Needed" is provided, including various allen keys, a guide pin tool, cassette tool, torque wrench, grease, and Blue (243) Loctite. The assembly steps cover pressing shock eyelet spacers, installing bearing lockrings, applying Blue Loctite to cap screws and washers, installing the Switch Infinity Link, greasing and installing extender bearing races, assembling shock extenders with a titanium female bolt and male bolt, greasing and installing the link pivot female bolt, applying grease to the rear triangle and main pivot collet axle, installing keyed bolts for the seatstay pivot, greasing and installing the large collet wedge bolt, installing collet axles for the shock, installing the lower cable port cover, and greasing and installing the derailleur hanger. Each step includes specific torque values where applicable.

An "Exploded View" diagram and "Exploded View Parts List" are provided, illustrating all components of the frame and listing their part numbers, descriptions, and quantities. This is crucial for identifying parts during assembly and maintenance.

"Rebuild Kits" and "Rebuild Kits Continued" sections list various kits available for the SB130, including the SB130 Hardware Kit, SB130 Master Rebuild Kit, SB130 Bearing Rebuild Kit, SB130 Port Cover Kit, and SB130 Gen 1 Protector Kit. Each kit lists its part number, description, and the quantity of components included.

Finally, the manual details Yeti's "Lifetime Warranty." All 2019 (or newer) frames, including the Switch Infinity, are covered for life against manufacturing defects for the original purchaser. Paint and finish are covered for one year. Yeti will repair or replace defective frames at its discretion, provided the bike is registered online and taken to an authorized dealer. The warranty does not cover damage from ordinary wear and tear, neglect, or intentional destruction. For crash or non-warranty situations, Yeti offers a reasonable replacement price. The lifetime warranty applies to all 2019 and newer frames, while 2018 and older frames are covered under previous warranty terms (5-year or 2-year based on purchase time). A "Disclaimer" clarifies that Yeti Cycles is not responsible for damages arising from riding, transporting, or other use of the bicycle, and its liability is limited to repair or replacement of the frame as per warranty terms. Users are advised to contact an authorized Yeti dealer for warranty concerns. Contact information for Yeti Cycles, including address, phone numbers, and website, along with business hours, is also provided.
