YMGI WMMS-09EW-V2B(59)2 User Manual

INSTALLER'S INSTRUCTION
P15 OF 46
YMGI, Engineered Comfort Products for A Sustainable and Efficient Green World !
SYSTEM LAYOUT & INSTALLATION CLEARANCE
CLEARANCE REQUIRED AROUND UNITS-TRIPLE ZONE-3
Indoor unit A
Indoor unit B
Indoor unit C
OVER 20"
OVER 10"
OVER 10"
OVER 8"
OVER 10"
OVER 2"
OVER 4" OVER 4"
OVER 80"
INSTALLER'S INSTRUCTION
P16 OF 46
YMGI, Engineered Comfort Products for A Sustainable and Efficient Green World !
SYSTEM LAYOUT & INSTALLATION CLEARANCE
CLEARANCE REQUIRED AROUND UNITS-QUAD ZONE-4
Indoor unit A
Indoor unit B
Indoor unit C
Indoor unit D
OVER 20"
OVER 10"
OVER 10"
OVER 8"
OVER 10"
OVER 2"
OVER 4" OVER 4"
OVER 80"
