Yoder Smokers YS640 User Manual

37
Yoder YS 640
37
ITEM # PART # DESCRIPTION QTY.
1 90737
HINGE, STAINLESS
2
2 1024X12FHMSSS
FLATHEAD MACHINE SCREW, STAINLESS
8
3 1024WHN
12-24 WHIZ NUT
8
4 22860
SERIAL NUMBER TAG
1
5 236-2489-02
POP RIVET
4
6 W90780
640 DOOR
1
7 41435
HANDLE, ROD
1
8 22866
HANDLE, SPRING
2
9 22924
PUSH CAP, 3/8”
2
10 90901
UNIVERSAL CHROME COOKING GRATE, 8”
4
11 90552
HEAT DIFFUSER
1
12 W90813
ADJUSTABLE BAFFLE
1
13 1213WHN
NUT, HEX, 1/2-13
2
14 W90814
BAFFLE HANDLE
1
15 W90348
640 SECOND SHELF
1
16 23108
PUSH CAP, 1/2”
1
17 90377
THUMBSCREW, 5/16-18 X 3/4
1
18 W90067
CHIMNEY
1
19 1420X12SHCS
SOCKET HEAD SCREW, 1/4-20X1/2
1
20 1420WHN
NUT, WHIZ, 1/4-20
3
21 90117FLP
HOPPER MOUNTING BRACKET
1
22 1420X58WHB
BOTL, WHIZ, 1/4-20 X 5/8” LONG
2
23 90460
BUCKET
1
24 W90779
32” SMOKE CHAMBER
1
25 90896
SIDE SHELF
1
26 90895
FRONT SHELF, 32”
1
27 90352
LEFT ANGLE 2ND SHELF
1
28 90353
RIGHT ANGLE 2ND SHELF
1
640 COOKING COMPONENTS
