Yoder Smokers YS640 User Manual

39
Yoder YS 640
39
640 IGNITER AND THERMOCOUPLE COMPONENTS
ITEM # PART # DESCRIPTION QTY.
1 1420WHN
NUT, WHIZ, 1/4-20
1
2 10X34HHSDS
SCREW, HEX HEAD, SELF DRILLING, 10 X 3/4
2
3 632X38MS
SCREW, MACHINE, ROUND HEAD, 6-32 X 3/8 LONG
4
4 632HN
NUT, HEX, 6-32
4
5 90005
BURN GRATE
1
6 1420X14SHSS
SCREW, SET, SOCKET HEAD, 1/4-20 X 1/4
4
7 W90026
IGNITER TUBE
1
8 A90494
IGNITER ASSEMBLY
1
9 90461LFP
THERMOCOUPLER MOUNT
1
10 90454
THERMOCOUPLER
1
11 W90794
SMOKE CHAMBER
1
12 W90809
AUGER COVER
1
13 W90811
FIREBOX
1
14 1420X1HB
BOLT, HEX, 1/4-20 X 1” LONG
1
