Yokis E2BPP User Manual

3 . How to set the pushbutton as centralised
1 . Press the transmitter pushbutton 10 times (Configuration Menu). The transmitter LED will flash rapidly.
2 . Press the chosen pushbutton 6 times while the LED is flashing.
3 . At the end of the press sequence, the LED will flash 6 times to confirm the configuration.
4 . How to set centralisation to operate lights (default) or window shutters
The centralised pushbutton will operate the light modules by default (MTR2000ER and MTV500ER). Skip this step.
If you want the centralised control to operate the MVR500ER window shutter modules:
1 . Press any pushbutton on the transmitter 10 times (Configuration Menu). The transmitter LED will flash rapidly.
2 . Press the chosen pushbutton 11 times while the LED is flashing.
3 . At the end of the press sequence, the LED will flash once (1 press) to confirm the configuration.
5 . How to define pushbutton operating mode
Follow the instructions in the next paragraph to establish the effect of the centralised pushbutton on the lights or window
shutter modules.
P U S H B U T T O N O P E R A T I N G M O D E
* Default configuration
To change the operating mode of a pushbutton:
1 - Press any pushbutton on the transmitter 10 times (Configuration Menu).
The transmitter LED will flash rapidly.
2 - While the LED is flashing, press the chosen button from 1 to 4 times to select the required operating function.
3 - The LED will flash from 1 to 4 times to confirm configuration.
U S E F U L F U N C T I O N S
How to copy a pushbutton onto another pushbutton (between two different transmitters or on the same transmitter).
Only the first of the configured connections will be copied: the new button will be set to operating mode 1 (toggle)
1- Press the new button to be created 5 times . The LED will start flashing.
2- While the LED is flashing, press the button to copied until the LED flashes.
How to copy a pushbutton (between two different transmitters)
All connections will be copied: the new button will be set to operating mode 1 (toggle)
On the new transmitter:
1- Press any pushbutton on the transmitter 10 times (Configuration Menu). The transmitter LED will flash rapidly.
2- While the LED is flashing, press the destination pushbutton 12 times . The LED will flash signalling wait state for
approximately 30 seconds.
On the source transmitter:
1- Press any pushbutton on the transmitter 10 times (Configuration Menu). The transmitter LED will flash rapidly.
2- While the LED is flashing, press the pushbutton to be copied 13 times . The LED will light up during data transfer and then
switch off.
How to duplicate the transmitter completely
On the new transmitter:
1- Press any pushbutton on the transmitter 10 times (Configuration Menu).
The transmitter LED will flash rapidly.
2- Press one of the pushbuttons 14 times while the LED is flashing.
3- The LED will flash at the end of the 14 presses.
On the source transmitter:
1- Press any pushbutton on the transmitter 10 times (Configuration Menu).
The transmitter LED will flash rapidly.
2- Press one of the pushbuttons 14 times while the LED is flashing.
3- The LED will flash at the end of the 14 press sequence.
P10
OPER
A
TING
MODE
MTR2000ER
MTV500ER
MVR500ER
Operating
mode
1*
On
/
Off
Dim
/
Off
Up
/
Stop
/
Down
Operating
mode
2
-
Recall
Memory
Level
Intermediate
position
Operating
mode
3
On
On
Up / Stop
Operating
mode
4
O
f
f
O
f
f
Down / Stop
DS1054
-
009A
