12
IM700938-01E
French
AVERTISSEMENT
• Afin d’éviter tout risque de choc électrique, il faut toujours débrancher le
cordon d’alimentation de la prise avant de remplacer le fusible.
• Toujours remplacer le fusible par un nouveau fusible à la valeur
spécifiée.
Ne jamais utiliser un fusible d’un autre calibre que celui spécifié, et, ne
pas court-circuiter le porte-fusible, pour éviter un accident entraînant
des blessures graves voire mortelles.
100 V, 120 V: F1.0 AL/250 V 20 mm x 5 mm dia.
220 V, 240 V: F0.5 AL/250 V 20 mm x 5 mm dia.
Replace the power fuse and change the supply voltage in the following
manner.
1
Turn OFF the power switch and unplug the power cord.
2
Insert a tool such as a flathead screwdriver into the fuse holder notch in
the power supply inlet, and use it to pry out the fuse holder.
3
When Replacing the Power Fuse Replace the power fuse with another
fuse of the specified rating. When Switching the Current Voltage
(1) Remove the voltage selector box from the fuse holder, rotate the box
so that the desired voltage can be seen through the viewing window,
then reinsert it into the fuse holder. Confirm that the desired voltage
setting appears in the viewing window. (The display will be upside
down.)
(2) Replace the power fuse with another fuse of the specified rating.
4
Reinsert the fuse holder into the power inlet.
Screwdriver
Fuse holder
AC Inlet
Use a tool such as a
flathead screwdriver to
pry out the fuse holder.
Fuse Replacement
To Next Page
