• Timeaxiszoom(Releasenumber3orlater)
Specify this setting when Action is set to Favorite.
Setting Description
Current Historical trend displays that have been registered to the favorite key are
displayed using the current time axis zoom.
Saved Historical trends are displayed using the time axis zooms that they were
registered with.
Procedure
• RegisteringtheDisplay
Up to 8 displays can be registered.
1.
In the operation mode, show the display you want to register.
2.
Press FUNC.
The FUNC key menu appears.
3.
Press the Favoriteregist soft key. Then, press a registration number softkey.
4.
Press the Regist soft key.
A window appears for you to enter the display name.
* To delete a registration, press the Delete soft key.
5.
Enter the display name (using up to 16 characters,
A a # 1
).
6.
Press DISP/ENTER.
The display is registered.
• SwitchingtheDisplay
 WhenYouSetActiontoHistory
The historical trend of the currently displayed data appears when you press the
favorite key. Press the key again to return to the previous display.
 WhenYouSetActiontoFavorite
The displays change in the order that they were registered in each time you press the
favorite key. Pressing the favorite key after the last registered display appears returns
the display to what it was before the favorite key was pressed.
5.16UsingtheFavoriteKey
