YOKOGAWA Daqstation DX2020 User Manual

6-7
IM 04L42B01-01E
Saving and Loading Data
1
2
3
4
5
6
7
8
9
10
11
12
13
App
Index
SetupItems
• Batch>On/Off
Select On to use the batch function.
For details on MultiBatch, see IM04L41B01-03E.
• Batch>Lot-No.digit
Select the number of digits of the lot number from 4, 6, or 8. Select Off to disable the
lot number.
• Batch>Autoincrement
Settings Description
On Automatically sets the lot number of the next measurement to “the lot number of
the current measurement + 1.”
Off Disables the operation described above.
• Datafilename>Structure
Batch: Sets the name of the display data files or event data files to “sequence number
+ batch name.”
For details on the data file name, see section 1.4.
• Textfieldnumber
Select a number from 1 to 24 on a DX whose release number is 3 or later. Select a
number from 1 to 8 on a DX whose release number is 2 or earlier.
• Textfield>Titleoffield,Textfield>Characters
Set the string.
Title of field: (Up to 20 characters,
A a # 1
), Characters: (Up to 30 characters,
A a # 1
)
Procedure
• SettingtheBatchName(Batchnumber+lotnumber)andComment
1.
In the operation mode, press FUNC.
The FUNC key menu appears.
2.
Press the Batch soft key.
A window appears for you to enter the batch name and comment.
3.
Set the batch number. (Up to 32 characters,
A a # 1
)
Symbols that can be used: #, %, (, ), +, -, ., @, °, and _.
If you are using the lot number, set the lot number.
4.
Set batch comments 1, 2, and 3. (Up to 50 characters each,
A a # 1
)
5.
Press DISP/ENTER.
Note
• Batchnumbersandlotnumberscannotbechangedaftermemorystart.
• Youcanchangethecommentasmanytimesasyouwishbeforeexecutingmemorystart.
After memory start, only the comments that are not specified can be entered. You can
change the comment as many times as you wish while the window for setting the comment
is displayed. The last specified comment is valid.
• Thecommentisclearedwhenmemorystopisexecuted.
• Thetextfieldssetuponmemorystart(see“StartingRecording(MemoryStart)”onthenext
page) are cleared upon memory stop.
• Thebatchnumber,lotnumber,andcommentsaresavedtothedisplaydatafileorevent
data file. They are not saved to the setup file.
6.3UsingtheBatchFunction
