YOKOGAWA Daqstation DX2020 User Manual

6-22
IM 04L42B01-01E
• LoadingtheSetupDatafortheSettingModeandBasicSettingMode
1.
Carry out the procedure below to show the display.
On DXs without the /AS1 advanced security option
Press MENU (to switch to setting mode), hold down FUNC for 3 s (to switch to
basic setting mode), and select the File/Initialize tab > Loadsettings. Press the
CF or USB soft key
*
, and then press DISP/ENTER.
* When you are using a CF card and USB flash memory (/USB1 option).
On DXs with the /AS1 advanced security option
Press MENU (to switch to setting mode), hold down FUNC for 3 s (to switch
to basic setting mode), and select the File/Initialize tab > Loadsettings > All
settings, Logininfoonly, or Othersettings. Press the CF or USB soft key*,
and then press DISP/ENTER.
* When you are using a CF card and USB flash memory (/USB1 option).
2.
Use DISP/ENTER and arrowkeys to select the setup file to be loaded.
* Setup data files are stored in the root directory [/].
To cancel the operation, press
ESC
.
3.
Press DISP/ENTER.
The setup data is loaded.
Note
For details on how to use the Sort key, see section 6.7.
6.9Saving/LoadingtheSetupData
