YOKOGAWA Daqstation DX2020 User Manual

6-25
IM 04L42B01-01E
Saving and Loading Data
1
2
3
4
5
6
7
8
9
10
11
12
13
App
Index
• SavingaTemplateFile
1.
Carry out the procedure below to show the display.
Press MENU (to switch to setting mode), and select the File tab > Savetemplate.
Press the CF or USB soft key*, and then press DISP/ENTER.
* When you are using a CF card and USB flash memory (/USB1 option).
Under Template File Status, the check boxes of the template files that are stored in the
internal memory are selected.
2.
Press a softkey to select a report type, and press DISP/ENTER.
The directories on the external storage medium appear. “/” is the root directory.
3.
Use the arrowkeys to select a directory, and press DISP/ENTER.
4.
Enter the file name (up to 32 characters,
A a # 1
).
Symbols that can be used: #, %, (, ), +, –, ., @, °, and _.
Strings that cannot be used: AUX, CON, PRN, NUL, CLOCK, COM1 to COM9, and LPT1 to
LPT9.
To cancel the operation, press
ESC
.
5.
Press DISP/ENTER.
The report template file is saved.
6.10LoadingandSavingReportTemplates(/M1and/PM1options;releasenumbers4andlater)
