9.6 CreatingaReportTemplate(Releasenumbers
4andlater)
This section explains how to make a report template.
To create a report template, you put keywords and text into cells in Excel.
Keywords specify the data that will be entered into a cell. Other text is included in the
report as it is written. Save the report templates that you create in XML spreadsheet
format. The report template file name extension is .xml.
For a description of the function, see section 1.8.
For the setting procedure, see section 9.5.
To load or save a report template, see section 6.10.
TemplateExample
Channel Number $Ch(R01)$ $Ch(R02)$
Name Tank1temperature Tank1pressure
Unit $Unit(R01)$ $Unit(R02)$
$ReportDataTime(Hour)$ $ReportDataInst(Hour,R01)$ $ReportDataInst(Hour,R02)$
$Repeat$ $Repeat$ $Repeat$
$Repeat$ $Repeat$ $Repeat$
ReportExample
Channel Number TIC-001 PIC-002
Name Tank1temperature Tank1pressure
Unit °C kPa
2010/04/01 00:00:00 76.5 45.6
2010/04/01 01:00:00 78.9 56.7
2010/04/01 02:00:00 77.7 50.8
