1-22
IM 04L42B01-01E
MessageSummary
Displays a list of written messages and the time the messages were written.
• Upto450messagescanbedisplayed.
• Upto50messagesthatareaddedtothepastdatasection(addedmessages)canbe
displayed.
• Youcanselectarbitrarymessageinformationandrecallthehistoricaltrendofthe
display data or event data that contains the message.
For the setting procedure, see section 4.7.
To the historical trend display
Number of the message displayed on the bottom line/number
of messages in the internal memory
Cursor (selects the message)
Message
Added message
(displayed in blue)
Date/Time when the message was written
Destination group to write the message
All groups or a group number
• SwitchingoftheDisplayItems
You can switch between two sets of display contents.
• Message,timewhenthemessagewaswritten,andgrouptowhichthemessage
was written
• Message,usernamethatwrotethemessage
1.3Display
