IM 12B07K02-01E
<
1.Specication
>
1-2
1.3
External
Dimensions
Unit: mm
15
16
13
14
11
12
150
19.6
22.5
Ø6.5
19.6
Ø25.9
PG7
Cable length (5 m or 10 m)
Standard type (FU20-
-T1-NPT)
Sensor body
(PPS resin)
(Note) Can be fixed to 3/4NPT female screw
.
3/4 inch
tapered thread
(Note)
3/4 inch
tapered thread
(Note)
Figure 1.1
FU20 pH/ORP Sensor
4th Edition : Nov
.20,2018-00
8
10
Table of Contents
