App.1-13
TI 32S01J30-01E
Appendix 1. US (FM) NI/Canada (FM) NI/IECEx Ex “ec”/ECAS-EX Ex “ec”
Yokogawa Electric Corporation
Model
ProSafe-RS/ProSafe-RS Lite
Title
Control drawing
No.
NFM014-A13
Page
12
Revision
78
(continued)
Classifications
Model
Ambient Temperature (*1)
Safety Node Units
L1NB10D-4
E
−20 to 70 °C
Unit for Optical Bus
Repeater Module
L1NT10D-2
E
−20 to 70 °C
Power supply Module
L1PW481-E3
−20 to 70 °C
L1PW484-E3
−20 to 70 °C
Bus interface module
L1SB401-E3 −20 to 70 °C
L1NT401-EF
−20 to 70 °C
L1NT501-EF
−20 to 70 °C
L1NT411-EF
−20 to 70 °C
L1NT511-EF
−20 to 70 °C
I/O module
L1AI143-
E
−20 to 70 °C
L1AI143-F −20 to 70 °C
L1AV144-SE3
−20 to 70 °C
L1AV144-SF3
−20 to 70 °C
L1AI533-HE3
−20 to 70 °C
L1AI533-HF3
−20 to 70 °C
L1AT145-SF3
−20 to 70 °C
L1AR145-SF3 −20 to 70 °C
L1DV144-SE
−20 to 70 °C
L1DV144-SF
−20 to 70 °C
L1DV531-LE
−20 to 70 °C
L1DV531-LF
−20 to 70 °C
L1DV541-SE
−20 to 70 °C
L1DV541-SF −20 to 70 °C
L1DV521-SF
−20 to 70 °C
L1DV53A-SF3
−20 to 70 °C
L1DCV01
−20 to 70 °C
Terminal block
L1TA4S-
0
−20 to 70 °C
L1TA4D-0
−20 to 70 °C
L1TB4S-0 −20 to 70 °C
L1TB4D-0
−20 to 70 °C
L1CCC01
−20 to 70 °C
L1CCC02
−20 to 70 °C
*1 The ambient temperature ranges are specified for the temperature around Field Control Unit,
Base Plate or Terminal Board, and not for the temperature around each model.
.
Dec. 3, 2021-00
