YOKOGAWA ProSafe-RS Technical Information

App.3-3
TI 32S01J30-01E
Appendix 3. IECEx Ex “ec”/ IECEx Type “n” of S2BN4D / S2BN5D
Appendix 3.2 IECEx Ex “ec”/ Intrinsic Safety/
ECAS-Ex Ex “ec” Information of S2BN5D
 Applicable Standards
IEC 60079-0 Ed. 7.0 (2017)
IEC 60079-7 Ed. 5.1 (2017)
IEC 60079-11 Ed.6.0 (2011)
 Markings
IECEx EXA 15.0003X
Ex ec [ia Ga] IIC T4 Gc
 Applicable Models
S2BN5D
 List of Parameters
Table List of Parameters (IECEx) of Base Plate for Barrier (S2BN5D)
Modules Uo (V) Io (mA) Po (mW) Ui (V) Co (nF) Lo (mH) Remarks
S2BN5D 30 — — 30 — — (*1)
*1: The used P+F’s I.S. barriers determine the ultimate output parameters of the channel. Please refer to P+F’s instruction manual
for the parameter of P+F’s I.S. barriers.
 Installation specications
• Ambient temperature -20 degree C to 70 degree C
• Ambient humidity 5 to 95%RH (no condensation)
• Location Indoor use
• Power supply
System power supply : 24 V DC +10 %/-14 %
Barrier power supply : 24 V DC +20 %/-10 %, up to 1.8 A
