App.1-29
TI 32S01J30-01E
Appendix 1. US (FM) NI/Canada (FM) NI/IECEx Ex “ec”/ECAS-EX Ex “ec”
Yokogawa Electric Corporation
Model
ProSafe-RS N-IO
Title
Control drawing
No.
NIE009-A101
Page
7
Revision
15
Notes:
1. No revision to this drawing without prior approval of FM.
2. In this control drawing, the term “installation” includes reconfiguration of the function of each
module, which is carried out in maintenance process.
3. Installation must be in accordance with the National Electrical Code (NFPA 70) and relevant local
codes.
4. In the course of installation, the related documents of GS (General specifications), TI (Technical
Information of Installation Guidance), and IM (User’s Manuals) should be referred to and the
instructions described in the documents should be observed.
5. Modules can be mounted also on an FM-approved Base Plate S2BN5D. In such case, installation
must be in accordance also with the control drawing of these Base Plates.
6. PROSAFE-RS IS SUITABLE FOR USE IN CLASS 1, DIVISION 2, GROUPS A, B, C, and D OR
NONHAZARDOUS LOCATIONS ONLY.
7. It must be observed during the installation that the venting slots of the devices are not blocked
by cable parts, fixing accessories etc.
8. The doors of the cabinets must be closed when ProSafe-RS is energized.
9. Nonincendive field wiring is permitted for the modules listed in tables of the nonincendive field
wiring parameters.
9.1 The nonincendive field wiring circuit concept allows interconnection of nonincendive field wiring
apparatus with associated nonincendive field wiring apparatus, using any of the wiring methods
permitted for unclassified locations.
9.2 Field equipment or other equipment connected to ProSafe-RS by nonincendive field wiring must
be FM approved.
9.3 The control drawing of field equipment or other equipment must be followed at the installation.
9.4 The following conditions must be met. See tables for the nonincendive field wiring parameters of
ProSafe-RS.
Vmax Voc or Vt; Imax Isc or It; Ca Ci + Ccable; La Li + Lcable
9.5 For current controlled circuits, Imax of the nonincendive field wiring apparatus is not required
and need not be aligned with parameter Isc or It of ProSafe-RS or other associated nonincendive
field wiring apparatus.
10. Use only the following batteries specified by Yokogawa Electric Corporation for the CPU modules:
SCP461: S9185FA, S2CP471: S9450FE.
11. Use only the following FANs specified by Yokogawa Electric Corporation for AIP602:
A1159EM or A1213EM
Dec. 3, 2021-00
A1159EM and A1213EM are components of AIP602. These are not sales units.
For actual replacement of the fan of ProSafe-RS, AIP602 shall be used.
