App.1-35
TI 32S01J30-01E
Appendix 1. US (FM) NI/Canada (FM) NI/IECEx Ex “ec”/ECAS-EX Ex “ec”
Yokogawa Electric Corporation
Model
ProSafe-RS N-IO
Title
Control drawing
No.
NIE009-A101
Page
13
Revision
15
Non-incendive field wiring parameters (Output parameter)
Model Function Voc
(
V
)
Isc
(
mA
)
Ca
(
μF
)
La
(
mH
)
Remark
S2MMM843
Redundant
Analog Input
(Current Input)
24.0 80.0 0.05 0.66
2-wire
transmitter
input
Single
Redundant
Analog Output
(Current Output)
28.0 23.0 0.05 0.66
Single
Redundant
Digital Input
30.0 7.2 0.05 0.66
(*1)
Single
Redundant
Digital Output
Nonincendive
field wiring
is not
permitted.
Single
S2MDV843
Redundant
Digital Input
30.0 7.2 0.05 0.66
(*1)
Single
Redundant
Digital Output
Nonincendive
field wiring
is not
permitted.
Single
*1 SCB100 and/or SCB110 may be connected. The connection of these adapters does not affect the
Non-incendive field wiring parameters in the table.
Non-incendive field wiring parameters (Input parameters)
Model Function Vmax
(
V
)
Imax
(
mA
)
Ci
(
μF
)
Li
(
μH
)
Remark
S2MMM843
Redundant
Analog Input
(Current Input)
30.0 0.02 10
4-wire
transmitter
input
Single
Dec. 3, 2021-00
