YOKOGAWA Rotamass Supreme User Manual

General Instruction Manual
Wiring
Transmitter
64 / 90
IM 01U10B00-00EN-R, 3rd edition, 2018-07-09
1. Switch off power supply.
2. Using an Allen wrench (Size: 3.0), tighten the locking screw on the back cover in
clockwise direction.
3. Unscrew back cover from transmitter housing in counter-clockwise direction.
4. Attach cable glands.
5. Connect wires to connection terminals.
NOTICE
Connect the grounding conductor to the grounding screw (see chapter Connection
terminals [}51], figure, point 2).
