YOKOGAWA Vnet/IP User Manual

  2.Vnet/IPNetworkConguration
2-4
TI 30A10A05-01E
Table Vnet/IP station IP address (1/2)
Station RequiredIPaddresses IP address Settingprocedure
HIS, ENG, SENG For bus 1 192.168.<dd>.<2×ss> Automatically set by the
DIP switch in Vnet/IP
interface cards.
For bus 2 192.168.<128+dd>.<2×ss>
Control bus TCP/IP
communications
172.16.<dd>.<ss> Manually set from the
Windows operating system,
System View of ENG, or
SENG SCS Manager.
For information network 172.17.<dd>.<ss>
FCS,
SCS
Single
CPU
For bus 1 192.168.<dd>.<2×ss> Automatically set by the
DIP switch.
For bus 2 192.168.<128+dd>.<2×ss>
Control bus TCP/IP
communications
172.16.<dd>.<ss> Set from either the System
View of ENG for FCS
or from the SENG SCS
Manager for SCS.
Duplexed
CPU
For bus 1(CPU1) 192.168.<dd>.<2×ss> Automatically set by the
DIP switch.
For bus 2(CPU1) 192.168.<128+dd>.<2×ss>
For bus 1(CPU2) 192.168.<dd>.<2×ss+1>
For bus 2(CPU2) 192.168.<128+dd>.<2×ss+1>
Control bus TCP/IP
communications
172.16.<dd>.<ss> Set from either the System
View of ENG for FCS
or from the SENG SCS
Manager for SCS.
APCS For bus 1 192.168.<dd>.<2×ss> Automatically set by the
DIP switch in Vnet/IP
interface cards.
For bus 2 192.168.<128+dd>.<2×ss>
For information network 172.17.<dd>.<ss> Manually set from the
Windows operating system,
System View of ENG.
UGS For bus 1 192.168.<dd>.<2×ss> Automatically set by the
DIP switch in Vnet/IP
interface cards.
For bus 2 192.168.<128+dd>.<2×ss>
For information network 172.17.<dd>.<ss> Manually set from the
Windows operating system,
System View of ENG.
For communications
(interface with PLC on Ethernet)
IP address for other PLC
network
Manually set from the
Windows operating system.
GSGW For bus 1 192.168.<dd>.<2×ss> Automatically set by the
DIP switch in Vnet/IP
interface cards.
For bus 2 <128+dd>.<2×ss>
For information network 172.17.<dd>.<ss> Manually set from the
Windows operating system,
System View of ENG
For communications
(interface with PLC on Ethernet)
IP address for other PLC
network
Manually set from the
Windows operating system.
SIOS For bus 1 192.168.<dd>.<2×ss> Automatically set by the
DIP switch in Vnet/IP
interface cards.
For bus 2 192.168.<128+dd>.<2×ss>
For information network 172.17.<dd>.<ss> Manually set from the
Windows operating system,
System View of ENG
For communications
(interface with PLC on Ethernet)
IP address for other PLC
network
Manually set from the
Windows operating system
Exaopc For bus 1 192.168.<dd>.<2×ss> Automatically set by the
DIP switch in Vnet/IP
interface cards.
For bus 2 192.168.<128+dd>.<2×ss>
For information network 172.17.<dd>.<ss> Manually set from the
Windows operating system.
dd: Domain number
ss: Station number
Aug.19,2011-00
