YOKOGAWA Vnet/IP User Manual

  2.Vnet/IPNetworkConguration
2-13
TI 30A10A05-01E
Table ExampleofaVnetrouterconguration(2/2)
Classication Settingitem Settingvalue Description
Constant Transfer system time Transfer lower Direction where to transmit system time during
time synchronization. Specify one of the
following directions (*1):
• Transfer lower: Upper domain to lower
domain
• Transfer upper: Lower domain to upper
domain
Vnet/IP
Domain
Target Domain (Check the check
box of the target
domain.)
When the transmission destination address
of a frame from a V net domain matches
the Vnet/IP domain denition, that frame is
transferred. In addition, only a broadcast frame
from a Vnet/IP domain specied in the Vnet/IP
domain is transferred to a V net domain.
It is not necessary to set a Vnet/IP domain to
which this V net router is connected because a
frame is always transferred in this case.
V net
Gateway
Station Name (Station name) (*2) Specify the station address and domain
number of the bus converter dened in a V net
domain. When the transmission destination
address of a frame from a Vnet/IP domain
matches the lower domain denition, that
frame is transferred. In addition, only a
broadcast frame from the domain specied in
the V net domain denition is transferred to a
Vnet/IP domain.
It is not necessary to set a V net domain to
which this V net router is connected because a
frame is always transferred in this case.
Domain Number (1~64)
*1: If operation mode is set to “Backward Compatible Mode”, this setting is xed at “Transfer lower.”
*2: BCVVddss, BCVHddss, or BCVLddss (dd:domain number, ss:station number)
Aug.19,2011-00
