  2.Vnet/IPNetworkConguration
2-12
TI 30A10A05-01E
Table ExampleofaVnetrouterconguration(1/2)
Classication Settingitem Settingvalue Description
Type Station Type AVR10D Type of V net router.
Apply Vnet/IP to Upper-Level
Domain
Check Bus type of the upper-level domain. The upper
upper-level domain can be Vnet/IP or V net.
Domain Number 2 Domain number of the upper-level domain.
Station Number 3 Station number of the upper-level domain.
Component Number (Up to 4 single-byte
characters)
Used for device identication. This setting can
be omitted.
Station Comment (Up to 24 single-
byte characters)
Used for device identication. This setting can
be omitted.
Alias of Station (Up to 8 single-byte
characters)
An alternative station name. This setting can
be omitted.
Station Status Display (Up to 16 single-
byte characters)
A window can be assigned to display the
station status on the HIS instead of using the
HIS station status display panel. This setting
can be omitted.
Upper Equipment Name (Equipment name
dened by Plant
Hierarchy Builder)
Name of the upper-level process equipment.
This setting can be omitted.
Constant Lower Address Domain Number: 1
Station Number: 3
Domain number and station number of the
lower-level domain.
FCS Message Communication -
Transfer upper
Check Specify whether or not to transfer FCS and
SCS messages generated on the lower-level
domain to the upper-level domain.
FCS Message Communication -
Transfer lower
Check Specify whether or not to transfer FCS and
SCS messages generated on the upper-level
domain to the lower-level domain.
HIS Message Communication -
Transfer upper
Check Specify whether or not to transfer HIS
messages generated on the lower-level
domain to the upper-level domain.
HIS Message Communication -
Transfer lower
Check Specify whether or not to transfer HIS
messages generated on the upper-level
domain to the lower-level domain.
Own Station Message
Communication - Transfer upper
Check Specify whether or not to transfer messages
generated on the V net router to the upper-
level domain.
Own Station Message
Communication - Transfer lower
Check Specify whether or not to transfer messages
generated on the V net router to the lower-level
domain.
Transfer TCP/IP to FCS Check Specify whether or not to transfer TCP/IP
communication between an HIS and FCS.
Select the check box to transfer the control bus
TCP/IP communication.
Operation Mode Standard Mode Behavior of the V net router. Specify one of the
following modes:
• Standard Mode: if you are using a new
AVR10D style S3 router
• Backward Compatible Mode: if you are using
the AVR10D style S3 router to replace an
AVR10D style S2 router
Repeating Capability 770pps Number of packets that the V net router can
send. Specify 450pps to achieve the same
performance as that of the AVR10D style S2
router.
Virtual Domain Link
Transmission
Invalid Specify whether or not to perform link
transmission between Vnet/IP and V net
domains.
Aug.19,2011-00
