333495-YTG-D-0609
Johnson Controls Unitary Products 15
BHZ036 (3.0 Ton)
Air on
Evaporator Coil
Temperature of Air on Condenser Coil
Net
Capacity
1
(MBh)
Total
Input
(kW)
2
Sensible Capacity (MBh)
Net
Capacity
1
(MBh)
Total
Input
(kW)
2
Sensible Capacity (MBh)
CFM
WB
(°F)
Return Dry Bulb (°F) Return Dry Bulb (°F)
90 85 80 75 70 65 90 85 80 75 70 65
75°F 85°F
900
77 39.2 2.6 19.4 15.1 10.8 - - - 39.6 2.7 20.6 16.3 12.0 - - -
72 38.5 2.4 27.0 22.7 18.4 14.2 - - 37.6 2.6 27.1 22.8 18.5 14.2 - -
67 37.7 2.2 34.6 30.3 26.1 21.8 17.5 - 35.5 2.6 33.6 29.3 25.0 20.7 16.5 -
62 34.8 2.2 34.8 34.8 32.3 28.0 23.7 19.5 33.2 2.5 33.2 33.2 30.9 26.6 22.3 18.1
57 34.5 2.3 34.5 34.5 32.4 28.1 23.9 19.6 32.9 2.6 32.9 32.9 30.8 26.6 22.3 18.0
1050
77 40.4 2.6 22.9 16.8 11.8 - - - 40.3 2.8 24.8 17.9 12.9 - - -
72 39.6 2.5 30.1 25.0 20.0 14.9 - - 38.2 2.7 30.0 24.9 19.9 14.8 - -
67 38.8 2.3 37.2 33.3 28.2 23.2 18.1 - 36.1 2.6 35.1 31.9 26.9 21.8 16.7 -
62 35.8 2.3 35.8 35.8 35.0 29.9 24.8 19.8 33.8 2.6 33.8 33.8 33.2 28.1 23.0 18.0
57 35.5 2.3 35.5 35.5 35.1 30.0 25.0 19.9 33.5 2.6 33.5 33.5 33.1 28.1 23.0 17.9
1200
77 41.6 2.7 26.5 18.5 12.7 - - - 40.9 2.9 29.1 19.6 13.8 - - -
72 40.7 2.5 33.2 27.3 21.5 15.7 - - 38.8 2.8 32.9 27.1 21.2 15.4 - -
67 39.8 2.4 39.8 36.2 30.4 24.5 18.7 - 36.7 2.7 36.7 34.5 28.7 22.9 17.0 -
62 36.8 2.4 36.8 36.8 37.6 31.8 26.0 20.1 34.3 2.7 34.3 34.3 35.4 29.6 23.8 17.9
57 36.5 2.4 36.5 36.5 37.7 31.9 26.1 20.3 34.1 2.7 34.1 34.1 35.4 29.5 23.7 17.9
1350
72 41.2 2.6 36.3 29.4 22.8 16.1 - - 39.5 2.9 35.9 29.3 22.7 16.0 - -
67 40.3 2.4 40.3 38.5 32.1 25.5 18.9 - 37.3 2.8 37.3 36.2 30.6 24.0 17.3 -
62 37.3 2.4 37.3 37.3 37.7 31.0 24.4 17.7 34.9 2.7 34.9 34.9 35.4 28.8 22.1 15.5
57 36.9 2.5 36.9 36.9 37.5 30.9 24.3 17.6 34.6 2.8 34.6 34.6 35.3 28.6 22.0 15.3
1500
72 41.7 2.7 39.5 31.5 24.0 16.6 - - 40.1 3.0 39.0 31.5 24.1 16.6 - -
67 40.8 2.5 40.8 40.8 33.9 26.5 19.0 - 37.9 2.9 37.9 37.9 32.5 25.1 17.6 -
62 37.7 2.5 37.7 37.7 37.7 30.3 22.8 15.4 35.4 2.8 35.4 35.4 35.4 28.0 20.5 13.1
57 37.3 2.5 37.3 37.3 37.3 29.9 22.4 15.0 35.2 2.9 35.2 35.2 35.2 27.7 20.2 12.8
95°F 105°F
900
77 40.0 2.9 21.7 17.5 13.2 - - - 37.1 3.4 20.1 15.8 11.6 - - -
72 36.7 2.9 27.1 22.8 18.6 14.3 - - 33.6 3.4 25.5 21.3 17.0 12.7 - -
67 33.4 2.9 32.5 28.2 24.0 19.7 15.4 - 30.1 3.3 29.6 26.7 22.4 18.2 13.9 -
62 31.6 2.8 31.6 31.6 29.5 25.2 20.9 16.6 28.7 3.2 28.7 28.7 26.3 22.0 17.8 13.5
57 31.4 2.8 31.4 31.4 29.3 25.0 20.7 16.4 28.6 3.3 28.6 28.6 26.2 22.0 17.7 13.4
1050
77 40.2 3.0 26.7 19.1 14.0 - - - 37.4 3.5 26.1 18.3 12.4 - - -
72 36.8 3.0 29.9 24.8 19.8 14.7 - - 33.8 3.4 28.4 23.4 18.3 13.2 - -
67 33.5 3.0 33.1 30.6 25.5 20.4 15.4 - 30.3 3.4 30.1 28.4 24.2 19.1 14.1 -
62 31.7 2.9 31.7 31.7 31.3 26.3 21.2 16.2 28.9 3.3 28.9 28.9 28.3 23.3 18.2 13.2
57 31.5 2.9 31.5 31.5 31.1 26.1 21.0 16.0 28.8 3.3 28.8 28.8 28.3 23.2 18.1 13.1
1200
77 40.3 3.1 31.6 20.7 14.9 - - - 37.6 3.6 32.0 20.7 13.3 - - -
72 37.0 3.1 32.6 26.8 20.9 15.1 - - 34.1 3.5 31.3 25.4 19.6 13.8 - -
67 33.6 3.1 33.6 32.9 27.0 21.2 15.4 - 30.5 3.4 30.5 30.1 25.9 20.1 14.2 -
62 31.9 3.0 31.9 31.9 33.2 27.4 21.6 15.7 29.1 3.4 29.1 29.1 30.3 24.5 18.7 12.8
57 31.6 3.0 31.6 31.6 33.0 27.2 21.3 15.5 29.0 3.4 29.0 29.0 30.3 24.4 18.6 12.8
1350
72 37.7 3.2 35.6 29.2 22.5 15.9 - - 34.5 3.6 33.1 27.2 20.6 13.9 - -
67 34.3 3.2 34.3 33.9 29.1 22.4 15.8 - 30.9 3.5 30.9 30.7 27.1 20.5 13.9 -
62 32.5 3.1 32.5 32.5 33.2 26.6 19.9 13.3 29.5 3.5 29.5 29.5 30.1 23.5 16.8 10.2
57 32.3 3.1 32.3 32.3 33.0 26.3 19.7 13.1 29.4 3.5 29.4 29.4 30.0 23.4 16.7 10.1
1500
72 38.5 3.3 38.5 31.6 24.1 16.7 - - 35.0 3.7 35.0 29.0 21.5 14.1 - -
67 35.0 3.3 35.0 35.0 31.1 23.7 16.2 - 31.3 3.6 31.3 31.3 28.4 20.9 13.5 -
62 33.2 3.2 33.2 33.2 33.2 25.7 18.3 10.8 29.9 3.6 29.9 29.9 29.9 22.4 15.0 7.5
57 33.0 3.2 33.0 33.0 33.0 25.5 18.1 10.6 29.8 3.6 29.8 29.8 29.8 22.3 14.9 7.4
