333495-YTG-D-0609
Johnson Controls Unitary Products 17
BHZ042 (3.5 Ton)
Air on
Evaporator Coil
Temperature of Air on Condenser Coil
Net
Capacity
1
(MBh)
Total
Input
(kW)
2
Sensible Capacity (MBh)
Net
Capacity
1
(MBh)
Total
Input
(kW)
2
Sensible Capacity (MBh)
CFM
WB
(°F)
Return Dry Bulb (°F) Return Dry Bulb (°F)
90 85 80 75 70 65 90 85 80 75 70 65
75°F 85°F
1050
77 52.7 3.0 26.6 21.6 16.6 - - - 47.6 3.2 24.7 19.7 14.8 - - -
72 48.9 2.9 34.3 29.3 24.4 19.4 - - 44.4 3.2 32.7 27.7 22.7 17.7 - -
67 45.1 2.8 43.9 37.1 32.1 27.1 22.1 - 41.2 3.2 40.6 35.6 30.6 25.6 20.6 -
62 44.0 2.8 44.0 44.0 42.6 37.6 32.6 27.7 38.8 3.1 38.8 38.8 38.2 33.2 28.2 23.2
57 43.6 2.8 43.6 43.6 41.8 36.8 31.8 26.8 39.4 3.1 39.4 39.4 38.5 33.5 28.5 23.5
1225
77 52.5 2.9 29.9 22.9 17.0 - - - 48.4 3.2 28.7 21.1 15.2 - - -
72 48.7 2.9 36.7 30.8 24.9 19.0 - - 45.2 3.2 35.1 29.3 23.4 17.5 - -
67 44.9 2.8 44.3 38.7 32.8 26.9 21.0 - 41.9 3.2 41.6 37.4 31.5 25.6 19.7 -
62 43.9 2.8 43.9 43.9 42.3 36.4 30.5 24.6 39.5 3.1 39.5 39.5 39.3 33.4 27.5 21.6
57 43.5 2.8 43.5 43.5 42.6 36.7 30.8 24.9 40.1 3.1 40.1 40.1 39.6 33.7 27.9 22.0
1400
77 52.3 2.9 33.2 24.1 17.3 - - - 49.3 3.2 32.6 22.4 15.6 - - -
72 48.5 2.9 39.0 32.2 25.4 18.6 - - 45.9 3.2 37.6 30.8 24.0 17.2 - -
67 44.7 2.8 44.7 40.2 33.4 26.6 19.8 - 42.6 3.2 42.6 39.2 32.4 25.6 18.8 -
62 43.8 2.8 43.8 43.8 41.9 35.1 28.3 21.5 40.2 3.1 40.2 40.2 40.4 33.6 26.8 20.0
57 43.3 2.8 43.3 43.3 43.5 36.7 29.9 23.1 40.8 3.1 40.8 40.8 40.8 34.0 27.2 20.4
1575
72 48.4 3.1 41.4 33.7 25.9 18.2 - - 46.7 3.4 40.2 32.5 24.7 17.0 - -
67 44.5 3.0 44.5 41.9 34.1 26.4 18.6 - 43.3 3.3 43.3 41.1 33.3 25.6 17.8 -
62 43.7 3.0 43.7 43.7 42.7 35.0 27.3 19.5 40.9 3.3 40.9 40.9 41.0 33.2 25.5 17.7
57 43.2 3.0 43.2 43.2 43.5 35.8 28.1 20.3 41.5 3.3 41.5 41.5 41.5 33.7 26.0 18.2
1750
72 48.2 3.3 43.9 35.2 26.5 17.8 - - 47.5 3.5 42.8 34.1 25.4 16.7 - -
67 44.4 3.3 44.4 43.6 34.9 26.2 17.5 - 44.1 3.5 44.1 43.0 34.3 25.6 16.9 -
62 43.6 3.2 43.6 43.6 43.6 34.9 26.2 17.5 41.6 3.4 41.6 41.6 41.6 32.9 24.2 15.5
57 43.1 3.2 43.1 43.1 43.6 34.9 26.2 17.5 42.2 3.4 42.2 42.2 42.2 33.5 24.8 16.1
95°F 105°F
1050
77 42.5 3.5 22.9 17.9 12.9 - - - 39.6 3.8 22.3 17.3 12.3 - - -
72 39.9 3.5 31.0 26.0 21.0 16.0 - - 36.3 3.7 29.9 24.9 19.9 14.9 - -
67 37.3 3.5 37.3 34.1 29.1 24.1 19.2 - 33.0 3.7 33.0 31.4 27.4 22.4 17.4 -
62 33.7 3.4 33.7 33.7 33.7 28.7 23.7 18.8 30.6 3.6 30.6 30.6 30.6 25.6 20.6 15.6
57 35.2 3.4 35.2 35.2 35.2 30.2 25.3 20.3 31.9 3.7 31.9 31.9 31.9 26.9 21.9 16.9
1225
77 44.4 3.5 27.5 19.3 13.4 - - - 41.2 3.9 28.3 19.6 12.8 - - -
72 41.6 3.5 33.6 27.7 21.8 16.0 - - 37.7 3.9 32.4 26.5 20.6 14.7 - -
67 38.9 3.5 38.9 36.2 30.3 24.4 18.5 - 34.3 3.8 34.3 32.9 28.5 22.6 16.7 -
62 35.2 3.4 35.2 35.2 36.3 30.4 24.5 18.6 31.8 3.8 31.8 31.8 32.8 26.9 21.0 15.1
57 36.8 3.4 36.8 36.8 36.6 30.8 24.9 19.0 33.2 3.8 33.2 33.2 33.3 27.4 21.5 15.6
1400
77 46.2 3.5 32.1 20.7 13.9 - - - 42.7 4.0 34.3 21.9 13.3 - - -
72 43.4 3.5 36.3 29.5 22.7 15.9 - - 39.2 4.0 35.0 28.2 21.4 14.6 - -
67 40.5 3.6 40.5 38.2 31.4 24.6 17.8 - 35.6 3.9 35.6 34.5 29.5 22.7 15.9 -
62 36.6 3.5 36.6 36.6 38.9 32.1 25.3 18.5 33.0 3.9 33.0 33.0 35.0 28.2 21.4 14.6
57 38.3 3.5 38.3 38.3 38.1 31.3 24.5 17.6 34.4 3.9 34.4 34.4 34.7 27.9 21.1 14.2
1575
72 45.1 3.6 39.0 31.2 23.5 15.7 - - 40.6 4.0 37.2 29.9 22.1 14.4 - -
67 42.1 3.6 42.1 40.3 32.5 24.8 17.0 - 37.0 4.0 37.0 36.0 30.5 22.8 15.0 -
62 38.1 3.5 38.1 38.1 39.2 31.5 23.7 16.0 34.3 3.9 34.3 34.3 35.3 27.5 19.8 12.0
57 39.8 3.5 39.8 39.8 39.4 31.7 23.9 16.2 35.7 3.9 35.7 35.7 35.7 27.9 20.2 12.4
1750
72 46.8 3.7 41.7 33.0 24.3 15.6 - - 42.1 4.0 39.5 31.6 22.9 14.2 - -
67 43.7 3.7 43.7 42.4 33.7 25.0 16.3 - 38.3 4.0 38.3 37.6 31.5 22.8 14.1 -
62 39.6 3.6 39.6 39.6 39.6 30.9 22.2 13.5 35.5 3.9 35.5 35.5 35.5 26.8 18.1 9.4
57 41.3 3.6 41.3 41.3 40.8 32.1 23.4 14.7 37.0 4.0 37.0 37.0 36.7 28.0 19.3 10.6
