333495-YTG-D-0609
Johnson Controls Unitary Products 19
BHZ048 (4.0 Ton)
Air on
Evaporator Coil
Temperature of Air on Condenser Coil
Net
Capacity
1
(MBh)
Total
Input
(kW)
2
Sensible Capacity (MBh)
Net
Capacity
1
(MBh)
Total
Input
(kW)
2
Sensible Capacity (MBh)
CFM
WB
(°F)
Return Dry Bulb (°F) Return Dry Bulb (°F)
90 85 80 75 70 65 90 85 80 75 70 65
75°F 85°F
1200
77 61.1 3.3 32.3 25.1 17.8 - - - 58.8 3.4 30.4 24.0 17.5 - - -
72 57.7 3.1 40.9 33.6 26.4 19.1 - - 54.5 3.3 38.7 32.2 25.7 19.3 - -
67 54.2 2.8 49.4 42.2 34.9 27.7 20.4 - 50.2 3.3 47.0 40.5 34.0 27.5 21.0 -
62 47.9 2.8 47.9 47.9 43.1 35.8 28.6 21.3 45.8 3.2 45.8 45.8 41.3 34.9 28.4 21.9
57 49.1 2.8 49.1 49.1 43.6 36.3 29.1 21.8 46.3 3.1 46.3 46.3 41.6 35.1 28.7 22.2
1400
77 61.0 3.5 34.3 26.4 18.9 - - - 58.6 3.6 34.2 25.5 18.4 - - -
72 57.6 3.2 43.0 35.5 28.0 20.5 - - 54.3 3.5 41.3 34.2 27.0 19.9 - -
67 54.2 2.9 51.8 44.6 37.1 29.5 22.0 - 50.0 3.5 48.4 42.8 35.7 28.6 21.4 -
62 47.9 2.9 47.9 47.9 45.7 38.2 30.7 23.2 45.7 3.4 45.7 45.7 43.4 36.3 29.2 22.0
57 49.1 3.0 49.1 49.1 46.2 38.7 31.2 23.7 46.2 3.3 46.2 46.2 43.7 36.6 29.5 22.3
1600
77 61.0 3.7 36.2 27.8 20.0 - - - 58.4 3.8 37.9 27.0 19.2 - - -
72 57.6 3.4 45.2 37.4 29.6 21.8 - - 54.1 3.7 43.9 36.1 28.3 20.5 - -
67 54.1 3.1 54.1 47.0 39.2 31.4 23.7 - 49.8 3.7 49.8 45.2 37.4 29.6 21.9 -
62 47.8 3.0 47.8 47.8 48.3 40.6 32.8 25.0 45.5 3.6 45.5 45.5 45.5 37.7 29.9 22.2
57 49.0 3.1 49.0 49.0 48.9 41.1 33.3 25.6 46.0 3.4 46.0 46.0 45.8 38.0 30.2 22.5
1800
72 57.6 3.8 48.6 39.9 31.3 22.7 - - 54.1 3.9 47.0 38.3 29.7 21.0 - -
67 54.2 3.5 54.2 50.6 41.4 32.8 24.2 - 49.8 3.9 49.8 47.5 39.2 30.6 21.9 -
62 47.9 3.4 47.9 47.9 48.1 39.5 30.9 22.2 45.5 3.8 45.5 45.5 45.5 36.8 28.2 19.5
57 49.1 3.5 49.1 49.1 49.0 40.4 31.7 23.1 45.9 3.6 45.9 45.9 45.9 37.2 28.6 19.9
2000
72 57.7 4.2 52.0 42.5 33.0 23.5 - - 54.0 4.2 50.0 40.5 31.0 21.5 - -
67 54.3 3.8 54.3 54.3 43.7 34.2 24.7 - 49.7 4.1 49.7 49.7 41.0 31.5 22.0 -
62 47.9 3.8 47.9 47.9 47.9 38.4 28.9 19.4 45.4 4.0 45.4 45.4 45.4 35.9 26.4 16.9
57 49.1 3.8 49.1 49.1 49.1 39.6 30.1 20.6 45.9 3.8 45.9 45.9 45.9 36.4 26.9 17.4
95°F 105°F
1200
77 56.5 3.4 28.5 22.8 17.1 - - - 51.7 3.8 27.8 22.1 16.4 - - -
72 51.3 3.6 36.5 30.8 25.1 19.4 - - 46.4 3.8 35.7 30.0 24.3 18.6 - -
67 46.1 3.8 44.5 38.8 33.1 27.4 21.7 - 41.0 3.9 40.2 37.4 32.2 26.5 20.8 -
62 43.7 3.6 43.7 43.7 39.6 33.9 28.2 22.5 39.6 3.8 39.6 39.6 37.3 31.6 25.9 20.2
57 43.5 3.3 43.5 43.5 39.7 34.0 28.3 22.6 39.5 3.6 39.5 39.5 37.4 31.7 26.0 20.2
1400
77 56.2 3.7 34.1 24.5 17.8 - - - 51.7 4.1 34.4 24.3 16.8 - - -
72 51.0 3.8 39.5 32.8 26.1 19.3 - - 46.3 4.2 38.3 31.6 24.8 18.1 - -
67 45.8 4.0 45.0 41.1 34.3 27.6 20.9 - 41.0 4.2 40.6 38.6 32.9 26.2 19.5 -
62 43.5 3.8 43.5 43.5 41.1 34.4 27.6 20.9 39.5 4.1 39.5 39.5 38.1 31.4 24.6 17.9
57 43.3 3.5 43.3 43.3 41.2 34.4 27.7 21.0 39.4 3.9 39.4 39.4 38.2 31.5 24.7 18.0
1600
77 55.8 3.9 39.7 26.2 18.4 - - - 51.6 4.5 41.0 26.5 17.1 - - -
72 50.6 4.1 42.6 34.8 27.0 19.3 - - 46.2 4.5 40.9 33.1 25.4 17.6 - -
67 45.5 4.3 45.5 43.4 35.6 27.8 20.1 - 40.9 4.5 40.9 39.8 33.6 25.9 18.1 -
62 43.2 4.1 43.2 43.2 42.6 34.9 27.1 19.3 39.4 4.4 39.4 39.4 38.9 31.2 23.4 15.6
57 43.0 3.8 43.0 43.0 42.7 34.9 27.2 19.4 39.4 4.2 39.4 39.4 39.0 31.2 23.5 15.7
1800
72 50.5 4.1 45.3 36.7 28.1 19.4 - - 46.3 4.6 43.1 35.0 26.2 17.5 - -
67 45.3 4.3 45.3 44.3 37.0 28.3 19.7 - 40.9 4.6 40.9 40.4 34.8 26.0 17.3 -
62 43.0 4.1 43.0 43.0 42.8 34.1 25.5 16.8 39.5 4.5 39.5 39.5 39.2 30.5 21.7 13.0
57 42.8 3.8 42.8 42.8 42.7 34.1 25.4 16.8 39.4 4.3 39.4 39.4 39.2 30.5 21.7 13.0
2000
72 50.3 4.2 48.1 38.6 29.1 19.6 - - 46.3 4.6 45.2 36.8 27.1 17.4 - -
67 45.2 4.4 45.2 45.2 38.3 28.8 19.3 - 41.0 4.7 41.0 41.0 35.9 26.2 16.5 -
62 42.9 4.2 42.9 42.9 42.9 33.4 23.9 14.4 39.5 4.5 39.5 39.5 39.5 29.8 20.1 10.4
57 42.7 3.8 42.7 42.7 42.7 33.2 23.7 14.2 39.4 4.4 39.4 39.4 39.4 29.7 20.0 10.3
