333495-YTG-D-0609
Johnson Controls Unitary Products 21
BHZ060 (5.0 Ton)
Air on
Evaporator Coil
Temperature of Air on Condenser Coil
Net
Capacity
1
(MBh)
Total
Input
(kW)
2
Sensible Capacity (MBh)
Net
Capacity
1
(MBh)
Total
Input
(kW)
2
Sensible Capacity (MBh)
CFM
WB
(°F)
Return Dry Bulb (°F) Return Dry Bulb (°F)
90 85 80 75 70 65 90 85 80 75 70 65
75°F 85°F
1500
77 74.6 3.8 37.2 30.1 23.0 - - - 68.9 4.6 34.2 27.1 19.9 - - -
72 65.7 3.9 42.0 34.9 27.8 20.6 - - 62.7 4.6 42.6 35.5 28.4 21.3 - -
67 56.8 4.0 46.8 39.7 32.6 25.4 18.3 - 56.4 4.5 51.1 44.0 36.8 29.7 22.6 -
62 55.7 3.6 55.7 55.7 45.4 38.2 31.1 24.0 53.4 4.2 53.4 53.4 46.6 39.5 32.3 25.2
57 55.0 3.6 55.0 55.0 46.1 39.0 31.9 24.8 53.0 4.2 53.0 53.0 46.9 39.7 32.6 25.5
1750
77 76.7 4.1 41.6 33.6 25.1 - - - 70.0 4.8 39.3 29.6 21.1 - - -
72 67.6 4.2 47.6 39.2 30.7 22.3 - - 63.6 4.8 46.9 38.5 30.1 21.7 - -
67 58.5 4.4 53.5 44.8 36.4 27.9 19.5 - 57.3 4.7 54.6 47.5 39.0 30.6 22.2 -
62 57.3 3.9 57.3 57.3 50.3 41.8 33.4 25.0 54.2 4.4 54.2 54.2 49.4 41.0 32.6 24.1
57 56.7 3.9 56.7 56.7 51.0 42.6 34.2 25.8 53.7 4.4 53.7 53.7 49.7 41.3 32.8 24.4
2000
77 78.8 4.4 46.0 37.0 27.3 - - - 71.0 5.0 44.3 32.1 22.3 - - -
72 69.5 4.6 53.2 43.4 33.7 24.0 - - 64.6 5.0 51.2 41.5 31.8 22.1 - -
67 60.3 4.7 60.3 49.9 40.2 30.4 20.7 - 58.1 4.9 58.1 51.0 41.3 31.5 21.8 -
62 58.9 4.2 58.9 58.9 55.1 45.4 35.7 26.0 55.0 4.6 55.0 55.0 52.2 42.5 32.8 23.1
57 58.3 4.2 58.3 58.3 56.0 46.2 36.5 26.8 54.5 4.6 54.5 54.5 52.5 42.8 33.1 23.3
2250
72 73.2 4.5 60.4 49.3 38.2 27.1 - - 66.9 5.0 57.1 46.1 35.0 23.9 - -
67 63.6 4.6 63.6 58.0 45.8 34.7 23.6 - 60.2 4.9 60.2 56.5 45.4 34.3 23.3 -
62 62.1 4.2 62.1 62.1 60.2 49.1 38.0 27.0 57.0 4.7 57.0 57.0 55.6 44.5 33.5 22.4
57 61.4 4.1 61.4 61.4 60.3 49.2 38.1 27.0 56.5 4.6 56.5 56.5 55.5 44.4 33.4 22.3
2500
72 77.0 4.5 67.6 55.1 42.7 30.3 - - 69.2 5.1 63.0 50.6 38.2 25.8 - -
67 66.9 4.6 66.9 66.2 51.4 39.0 26.5 - 62.3 5.0 62.3 62.0 49.6 37.1 24.7 -
62 65.2 4.1 65.2 65.2 65.2 52.8 40.4 28.0 59.0 4.7 59.0 59.0 59.0 46.6 34.2 21.7
57 64.5 4.1 64.5 64.5 64.5 52.1 39.7 27.3 58.5 4.7 58.5 58.5 58.5 46.1 33.7 21.2
95°F 105°F
1500
77 63.3 5.5 31.1 24.0 16.9 - - - 57.8 5.8 29.5 22.4 15.3 - - -
72 59.7 5.2 43.2 36.1 29.0 21.9 - - 53.8 5.6 40.0 32.9 25.8 18.7 - -
67 56.1 4.9 55.3 48.2 41.1 34.0 26.8 - 49.8 5.4 49.4 43.4 36.3 29.1 22.0 -
62 51.2 4.9 51.2 51.2 47.8 40.7 33.6 26.4 45.7 5.3 45.7 45.7 43.6 36.5 29.4 22.2
57 50.9 4.9 50.9 50.9 47.6 40.5 33.3 26.2 46.5 5.3 46.5 46.5 42.1 34.9 27.8 20.7
1750
77 63.2 5.6 36.9 25.6 17.1 - - - 58.1 6.0 36.9 24.6 15.9 - - -
72 59.6 5.3 46.3 37.9 29.4 21.0 - - 54.1 5.8 43.7 35.2 26.8 18.4 - -
67 56.0 5.0 55.7 50.1 41.7 33.3 24.9 - 50.1 5.5 49.9 45.9 37.7 29.3 20.9 -
62 51.1 4.9 51.1 51.1 48.6 40.1 31.7 23.3 45.9 5.4 45.9 45.9 45.4 37.0 28.6 20.1
57 50.8 4.9 50.8 50.8 48.3 39.9 31.5 23.1 46.7 5.4 46.7 46.7 43.8 35.3 26.9 18.5
2000
77 63.2 5.7 42.6 27.1 17.4 - - - 58.4 6.1 44.2 26.8 16.5 - - -
72 59.6 5.4 49.3 39.6 29.9 20.2 - - 54.4 5.9 47.3 37.6 27.9 18.1 - -
67 56.0 5.1 56.0 52.1 42.3 32.6 22.9 - 50.3 5.7 50.3 48.4 39.2 29.5 19.7 -
62 51.1 5.0 51.1 51.1 49.3 39.6 29.9 20.1 46.2 5.5 46.2 46.2 47.2 37.5 27.8 18.0
57 50.8 5.0 50.8 50.8 49.1 39.3 29.6 19.9 47.0 5.5 47.0 47.0 45.4 35.7 26.0 16.3
2250
72 60.6 5.5 53.9 42.9 31.8 20.7 - - 55.6 6.0 51.3 40.6 29.5 18.4 - -
67 56.9 5.3 56.9 54.9 45.0 34.0 22.9 - 51.5 5.8 51.5 50.5 41.5 30.4 19.4 -
62 51.9 5.2 51.9 51.9 51.0 40.0 28.9 17.8 47.3 5.7 47.3 47.3 47.8 36.7 25.6 14.5
57 51.6 5.2 51.6 51.6 50.7 39.7 28.6 17.5 48.1 5.7 48.1 48.1 47.3 36.2 25.2 14.1
2500
72 61.5 5.7 58.5 46.1 33.7 21.3 - - 56.9 6.1 55.4 43.6 31.2 18.7 - -
67 57.8 5.4 57.8 57.8 47.7 35.3 22.9 - 52.7 5.9 52.7 52.7 43.8 31.4 19.0 -
62 52.8 5.3 52.8 52.8 52.8 40.3 27.9 15.5 48.3 5.8 48.3 48.3 48.3 35.9 23.5 11.1
57 52.4 5.3 52.4 52.4 52.4 40.0 27.6 15.2 49.2 5.8 49.2 49.2 49.2 36.8 24.3 11.9
