York Affinity BHZ042 - Page 22

333495-YTG-D-0609
40 Johnson Controls Unitary Products
036
(3.0)
900
55
MBH 11.61 13.92 16.68 19.98 23.94 28.67 34.32 41.09
KW 1.98 2.15 2.32 2.49 2.65 2.82 2.99 3.16
70
MBH 10.65 12.96 15.72 19.02 22.98 27.71 33.37 40.14
KW 2.34 2.51 2.68 2.85 3.02 3.19 3.36 3.53
80
MBH 9.30 11.61 14.37 17.67 21.63 26.36 32.02 38.79
KW 2.62 2.79 2.95 3.12 3.29 3.46 3.63 3.80
1050
55
MBH 11.98 14.29 17.05 20.36 24.31 29.04 34.70 41.47
KW 1.94 2.11 2.28 2.45 2.61 2.78 2.95 3.12
70
MBH 11.02 13.33 16.09 19.40 23.35 28.08 33.74 40.51
KW 2.30 2.47 2.64 2.81 2.98 3.15 3.32 3.49
80
MBH 9.67 11.98 14.74 18.05 22.00 26.73 32.39 39.16
KW 2.58 2.75 2.91 3.08 3.25 3.42 3.59 3.76
1200
55
MBH 12.72 15.03 17.80 21.10 25.05 29.78 35.44 42.21
KW 1.86 2.03 2.20 2.37 2.53 2.70 2.87 3.04
70
MBH 11.77 14.07 16.84 20.14 24.10 28.83 34.48 41.25
KW 2.22 2.39 2.56 2.73 2.90 3.07 3.24 3.41
80
MBH 10.42 12.72 15.49 18.79 22.75 27.48 33.13 39.90
KW 2.50 2.67 2.83 3.00 3.17 3.34 3.51 3.68
1350
55
MBH 13.10 15.41 18.17 21.47 25.43 30.16 35.81 42.58
KW 1.82 1.99 2.16 2.33 2.49 2.66 2.83 3.00
70
MBH 12.14 14.45 17.21 20.51 24.47 29.20 34.86 41.63
KW 2.18 2.35 2.52 2.69 2.86 3.03 3.20 3.37
80
MBH 10.79 13.10 15.86 19.16 23.12 27.85 33.51 40.28
KW 2.46 2.63 2.79 2.96 3.13 3.30 3.47 3.64
1500
55
MBH 13.28 15.59 18.35 21.66 25.61 30.34 36.00 42.77
KW 1.80 1.97 2.14 2.31 2.47 2.64 2.81 2.98
70
MBH 12.32 14.63 17.40 20.70 24.65 29.38 35.04 41.81
KW 2.16 2.33 2.50 2.67 2.84 3.01 3.18 3.35
80
MBH 10.97 13.28 16.05 19.35 23.30 28.03 33.69 40.46
KW 2.44 2.61 2.77 2.94 3.11 3.28 3.45 3.62
042
(3.5)
1050
55
MBH 14.34 17.01 20.13 23.79 28.08 33.09 38.97 45.85
KW 2.20 2.43 2.66 2.89 3.12 3.34 3.57 3.80
70
MBH 14.60 17.27 20.39 24.05 28.34 33.36 39.23 46.11
KW 2.72 2.95 3.18 3.41 3.63 3.86 4.09 4.32
80
MBH 13.11 15.77 18.90 22.56 26.84 31.86 37.74 44.62
KW 3.13 3.35 3.58 3.81 4.04 4.27 4.49 4.72
1225
55
MBH 14.84 17.51 20.63 24.29 28.58 33.59 39.47 46.35
KW 2.09 2.32 2.55 2.78 3.00 3.23 3.46 3.69
70
MBH 15.10 17.77 20.89 24.55 28.84 33.86 39.73 46.61
KW 2.61 2.84 3.07 3.29 3.52 3.75 3.98 4.21
80
MBH 13.61 16.27 19.40 23.06 27.34 32.36 38.24 45.12
KW 3.01 3.24 3.47 3.70 3.93 4.15 4.38 4.61
1400
55
MBH 15.34 18.01 21.13 24.79 29.08 34.09 39.97 46.85
KW 1.98 2.21 2.44 2.66 2.89 3.12 3.35 3.57
70
MBH 15.60 18.27 21.39 25.05 29.34 34.35 40.23 47.11
KW 2.50 2.73 2.95 3.18 3.41 3.64 3.86 4.09
80
MBH 14.11 16.77 19.90 23.56 27.84 32.86 38.74 45.62
KW 2.90 3.13 3.36 3.59 3.81 4.04 4.27 4.50
1575
55
MBH 15.54 18.21 21.33 24.99 29.28 34.29 40.17 47.05
KW 1.93 2.16 2.39 2.62 2.85 3.07 3.30 3.53
70
MBH 15.80 18.47 21.59 25.25 29.54 34.55 40.43 47.31
KW 2.45 2.68 2.91 3.14 3.36 3.59 3.82 4.05
80
MBH 14.31 16.97 20.10 23.76 28.04 33.06 38.94 45.82
KW 2.86 3.08 3.31 3.54 3.77 4.00 4.22 4.45
1750
55
MBH 15.62 18.29 21.41 25.07 29.35 34.37 40.25 47.13
KW 1.92 2.14 2.37 2.60 2.83 3.06 3.28 3.51
70
MBH 15.88 18.55 21.67 25.33 29.62 34.63 40.51 47.39
KW 2.43 2.66 2.89 3.12 3.35 3.57 3.80 4.03
80
MBH 14.39 17.05 20.18 23.84 28.12 33.14 39.02 45.90
KW 2.84 3.07 3.29 3.52 3.75 3.98 4.21 4.43
BHZ024-060 (Continued)
Size
(Tons)
Air Over Evaporator
Coil
Capacity
1
& kW
2
Outdoor Temperature (°F @ 72% RH)
CFM DB (°F
) -10 0 10 20 30 40 50 60
