294604-YTG-G-0511
Johnson Controls Unitary Products 29
DEQ042 (3.5 Ton)
Air on
Evaporator Coil
Temperature of Air on Condenser Coil
Net
Capacity
1
(MBh)
Total
Input
(kW)
2
Sensible Capacity (MBh)
Net
Capacity
1
(MBh)
Total
Input
(kW)
2
Sensible Capacity (MBh)
CFM
WB
(°F)
Return Dry Bulb (°F) Return Dry Bulb (°F)
90 85 80 75 70 65 90 85 80 75 70 65
75°F 85°F
1200
77 58.6 2.9 27.7 23.2 17.8 - - - 54.9 3.2 27.8 22.3 16.7 - - -
72 54.7 2.8 36.7 31.3 25.8 20.4 - - 50.8 3.1 35.5 29.9 24.4 - - -
67 50.8 2.8 45.7 39.3 33.9 28.4 23.0 - 46.7 3.0 43.1 37.6 32.0 26.5 20.9 -
62 46.3 2.7 46.3 46.2 42.8 37.3 31.9 26.5 42.8 2.9 42.8 42.7 39.3 33.7 28.2 22.6
57 45.4 2.6 45.4 45.4 43.0 37.5 32.1 26.7 42.3 2.9 42.3 42.3 39.9 34.3 28.8 23.2
1300
77 58.7 2.9 27.9 23.9 18.3 - - - 55.0 3.2 28.8 23.0 17.2 - - -
72 54.8 2.8 37.7 32.1 26.6 21.0 - - 50.9 3.1 36.7 30.9 25.2 19.4 - -
67 50.9 2.7 47.6 40.4 34.8 29.2 23.6 - 46.8 3.0 44.6 38.8 33.1 27.3 21.5 -
62 46.3 2.7 46.3 46.3 44.0 38.4 32.8 27.2 42.9 2.9 42.9 42.8 40.6 34.8 29.0 23.2
57 45.4 2.5 45.4 45.4 44.2 38.6 33.0 27.4 42.4 2.8 42.4 42.4 41.2 35.4 29.6 23.8
1400
77 58.7 2.9 28.1 24.5 18.8 - - - 55.1 3.2 29.8 23.8 17.8 - - -
72 54.8 2.8 38.8 33.0 27.3 21.5 - - 51.0 3.1 38.0 32.0 25.9 19.9 - -
67 50.9 2.7 49.4 41.5 35.8 30.0 24.3 - 46.8 3.0 46.1 40.1 34.1 28.1 22.1 -
62 46.3 2.7 46.3 46.3 45.2 39.4 33.7 27.9 42.9 2.9 42.9 42.9 41.9 35.8 29.8 23.8
57 45.4 2.5 45.4 45.4 45.4 39.7 33.9 28.2 42.5 2.8 42.5 42.5 42.5 36.5 30.5 24.5
1500
72 55.8 2.8 41.3 35.1 28.9 22.8 - - 51.5 3.1 39.8 33.4 27.0 20.5 - -
67 51.8 2.8 51.1 44.1 38.0 31.8 25.7 - 47.4 3.0 47.0 41.8 35.4 29.0 22.6 -
62 47.2 2.7 47.2 47.2 46.6 40.5 34.3 28.2 43.4 2.9 43.4 43.4 42.9 36.5 30.0 23.6
57 46.2 2.5 46.2 46.2 46.2 40.1 33.9 27.8 43.0 2.8 43.0 43.0 43.0 36.6 30.1 23.7
95°F 105°F
1200
77 51.2 3.4 27.9 21.3 15.6 - - - 46.6 3.7 28.1 20.0 14.1 - - -
72 46.8 3.3 34.2 28.6 22.9 17.2 - - 42.2 3.6 32.5 26.8 21.2 15.5 - -
67 42.5 3.2 40.6 35.8 30.1 24.5 18.8 - 37.8 3.5 36.9 33.7 28.3 22.6 16.9 -
62 39.3 3.2 39.3 39.2 35.8 30.1 24.4 18.8 34.7 3.4 34.7 34.7 31.7 26.1 20.4 14.7
57 39.3 3.1 39.3 39.3 36.8 31.1 25.4 19.7 35.2 3.4 35.2 35.2 33.0 27.3 21.7 16.0
1300
77 51.3 3.4 29.7 22.2 16.2 - - - 46.9 3.7 30.4 21.1 14.6 - - -
72 47.0 3.3 35.7 29.7 23.7 17.8 - - 42.5 3.6 34.0 28.0 22.0 16.1 - -
67 42.7 3.2 41.7 37.3 31.3 25.3 19.3 - 38.1 3.4 37.6 35.0 29.5 23.5 17.5 -
62 39.4 3.2 39.4 39.4 37.2 31.2 25.2 19.2 34.9 3.4 34.9 34.9 33.0 27.1 21.1 15.1
57 39.5 3.1 39.5 39.5 38.2 32.2 26.2 20.3 35.5 3.4 35.5 35.5 34.4 28.4 22.4 16.4
1400
77 51.5 3.4 31.5 23.1 16.8 - - - 47.2 3.7 32.7 22.1 15.2 - - -
72 47.2 3.3 37.2 30.9 24.6 18.3 - - 42.8 3.6 35.5 29.2 22.9 16.6 - -
67 42.8 3.2 42.8 38.7 32.4 26.2 19.9 - 38.4 3.4 38.4 36.3 30.6 24.3 18.1 -
62 39.5 3.1 39.5 39.5 38.5 32.3 26.0 19.7 35.2 3.4 35.2 35.2 34.4 28.1 21.8 15.5
57 39.6 3.1 39.6 39.6 39.6 33.3 27.0 20.8 35.7 3.4 35.7 35.7 35.7 29.4 23.2 16.9
1500
72 47.3 3.3 38.3 31.6 25.0 18.3 - - 42.6 3.6 36.4 29.7 23.0 16.3 - -
67 42.9 3.2 42.9 39.6 32.9 26.2 19.6 - 38.2 3.4 38.2 36.5 30.7 24.0 17.3 -
62 39.6 3.1 39.6 39.6 39.1 32.4 25.8 19.1 35.0 3.4 35.0 35.0 34.5 27.8 21.1 14.4
57 39.7 3.1 39.7 39.7 39.7 33.0 26.4 19.7 35.6 3.4 35.6 35.6 35.6 28.9 22.2 15.5
