York AFFINITY DEZ024 - Page 30

294604-YTG-G-0511
30 Johnson Controls Unitary Products
115°F 125°F
1200
77 42.0 4.0 28.4 18.7 12.5 - - - 37.4 4.2 29.6 18.3 11.0 - - -
72 37.6 3.8 30.8 25.1 19.5 13.8 - - 32.9 4.0 29.0 23.4 17.7 12.1 - -
67 33.2 3.7 33.2 31.5 26.4 20.7 15.1 - 28.5 3.9 28.5 28.5 24.5 18.9 13.2 -
62 30.1 3.6 30.1 30.1 27.6 22.0 16.3 10.7 25.5 3.8 25.5 25.5 23.5 17.9 12.3 6.6
57 31.2 3.6 31.2 31.2 29.2 23.5 17.9 12.2 27.1 3.9 27.1 27.1 25.4 19.7 14.1 8.5
1300
77 42.4 4.0 31.1 19.9 13.1 - - - 38.0 4.2 32.2 20.3 11.5 - - -
72 38.0 3.8 32.3 26.3 20.3 14.4 - - 33.5 4.0 30.6 24.6 18.7 12.7 - -
67 33.5 3.7 33.5 32.7 27.6 21.6 15.7 - 29.0 3.9 29.0 29.0 25.8 19.8 13.8 -
62 30.4 3.6 30.4 30.4 28.9 22.9 16.9 11.0 26.0 3.8 26.0 26.0 24.8 18.8 12.8 6.8
57 31.5 3.6 31.5 31.5 30.5 24.5 18.6 12.6 27.5 3.9 27.5 27.5 26.7 20.7 14.7 8.8
1400
77 42.9 4.0 33.8 21.2 13.7 - - - 38.6 4.2 34.9 22.3 12.1 - - -
72 38.4 3.8 33.9 27.5 21.2 14.9 - - 34.0 4.1 32.2 25.9 19.6 13.2 - -
67 33.9 3.7 33.9 33.9 28.8 22.5 16.2 - 29.5 3.9 29.5 29.5 27.0 20.7 14.4 -
62 30.8 3.6 30.8 30.8 30.2 23.9 17.6 11.3 26.4 3.8 26.4 26.4 26.0 19.7 13.4 7.0
57 31.9 3.6 31.9 31.9 31.9 25.6 19.3 13.0 28.0 3.9 28.0 28.0 28.0 21.7 15.4 9.0
1500
72 38.0 3.8 34.5 27.8 21.0 14.3 - - 33.3 4.0 32.6 25.8 19.1 12.3 - -
67 33.5 3.7 33.5 33.5 28.5 21.8 15.1 - 28.8 3.9 28.8 28.8 26.4 19.6 12.8 -
62 30.4 3.6 30.4 30.4 29.9 23.1 16.4 9.7 25.9 3.8 25.9 25.9 25.3 18.5 11.8 5.0
57 31.5 3.6 31.5 31.5 31.5 24.8 18.1 11.3 27.4 3.9 27.4 27.4 27.4 20.7 13.9 7.2
1. These capacities are Net Capacities.
2. These ratings include the compressor, condenser fan and supply air blower motors.
DEQ042 (3.5 Ton) (Continued)
Air on
Evaporator Coil
Temperature of Air on Condenser Coil
Net
Capacity
1
(MBh)
Total
Input
(kW)
2
Sensible Capacity (MBh)
Net
Capacity
1
(MBh)
Total
Input
(kW)
2
Sensible Capacity (MBh)
CFM
WB
(°F)
Return Dry Bulb (°F) Return Dry Bulb (°F)
90 85 80 75 70 65 90 85 80 75 70 65
