MODEL
DEB
POWER SUP
-
PLY
VOLTAGE
LIMITATIONS
1
COMPRESSOR
COND.
FAN
MOTOR,
FLA
SUPPLY
AIR
BLOWER
MOTOR,
FLA
MINIMUM
CIRCUIT
AMPACITY
MAX.
FUSE
SIZE,
AMPS
2
MAX.
HACR
BREAKER
SIZE,
AMPS
UNIT
POWER
FACTOR
TRANSFORMER
SIZE (VA)
MIN. MAX. RLA LRA
018 208/230-1-60 187 253 9.0 48.0 1.1 2.6 14.9 20 20 .96 40
024 208/230-1-60 187 253 11.5 60.0 1.1 2.6 18.1 25 25 .96 40
030 208/230-1-60 187 253 14.7 73.0 1.1 2.6 22.1 30 30 .96 40
036 208/230-1-60 187 253 17.3 94.0 1.1 3.5 26.2 35 35 .96 40
042 208/230-1-60 187 253 20.5 120.0 1.1 3.5 30.2 40 40 .96 40
048 208/230-1-60 187 253 24.4 140.0 1.3 4.0 35.8 45 45 .96 40
060 208/230-1-60 187 253 28.9 165.0 1.3 4.0 44.4 60 60 .96 40

= Rated in accordance with ARI Standard 110, utilization range “A”. = Dual element, time delay type.
TABLE 4 - ELECTRICAL DATA (BASIC UNIT)
* = KW listed is for 240 volts, use this table for 208 or 230 volts.
ELECTRIC HEAT
CORRECTION
FACTORS
NOMINAL VOLTAGE VOLTAGE
KW CAP. MULTI
-
PLIER
240
208
230
.75
.92
