343615-YTG-B-0308
Johnson Controls Unitary Products 15
TABLE 16: DY036 COOLING CAPACITIES (3 TON)
Air on Evap-
orator Coil
Temperature of Air on Condenser Coil
75°F 85°F
CFM
WB
(°F)
Total
Cap.
1
(MBH)
Total
2
Input
(kW)
Sensible Capacity (MBH)
1
Return Dry Bulb (°F)
Total
Cap.
1
(MBH)
Total
2
Input
(kW)
Sensible Capacity (MBH)
1
Return Dry Bulb (°F)
86 83 80 77 74 71 68 86 83 80 77 74 71 68
900
72 44 2.3 24 21 19 16 14 - - 41 2.5 23 20 18 15 12 - -
67 42 2.3 30 28 25 23 20 18 15 38 2.5 29 26 24 21 18 16 13
62 40 2.3 40 35 33 30 28 25 23 35 2.5 35 32 30 27 25 22 20
57 39 2.3 39 37 35 32 30 27 25 35 2.5 35 34 31 28 26 23 21
1050
72 44 2.2 26 23 20 17 14 - - 42 2.5 25 22 19 16 13 - -
67 42 2.3 33 30 27 24 21 18 15 39 2.5 31 28 25 22 19 16 13
62 40 2.3 40 38 35 32 29 26 23 35 2.5 35 34 32 29 26 23 20
57 39 2.3 39 38 37 34 31 28 25 35 2.5 35 35 33 30 27 24 21
1200
72 44 2.2 28 25 21 18 14 - - 43 2.5 27 24 20 17 13 - -
67 43 2.3 35 32 28 25 21 18 14 40 2.5 34 31 27 24 20 17 13
62 40 2.3 40 40 37 33 30 26 23 36 2.5 36 36 34 31 27 24 20
57 39 2.3 39 39 39 36 32 29 25 36 2.5 36 36 36 32 29 25 22
1350
72 45 2.2 30 26 22 18 14 - - 43 2.5 29 25 21 17 13 - -
67 43 2.3 37 33 29 25 21 18 14 40 2.5 36 32 28 24 20 16 12
62 41 2.3 41 41 39 35 31 27 23 37 2.5 37 37 36 32 28 24 20
57 40 2.3 40 40 40 36 32 28 24 36 2.5 36 36 36 32 28 24 20
1500
72 46 2.3 32 27 23 18 14 - - 44 2.5 31 27 22 18 13 - -
67 44 2.3 40 35 31 26 22 17 13 41 2.5 39 34 30 25 21 16 12
62 42 2.3 42 42 42 37 33 28 24 37 2.5 37 37 37 33 28 24 19
57 41 2.3 41 41 41 36 32 27 23 37 2.5 37 37 37 32 28 23 19
95°F 105°F
900
72 38 2.7 21 19 16 14 11 - - 35 3.0 20 17 15 12 10 - -
67 35 2.7 27 24 22 19 17 14 12 31 2.9 25 23 20 18 15 12 10
62 30 2.7 30 29 27 24 22 19 17 27 3.0 27 26 24 21 19 16 14
57 30 2.7 30 30 27 25 22 19 17 27 3.0 27 27 25 22 20 17 15
1050
72 39 2.7 24 21 18 15 12 - - 36 3.0 22 19 16 13 10 - -
67 36 2.7 30 27 24 21 18 15 12 32 2.9 28 25 22 19 16 13 10
62 31 2.7 31 31 30 26 23 20 17 28 2.9 28 28 26 23 20 17 14
57 31 2.7 31 31 30 27 24 21 18 28 2.9 28 28 27 24 21 18 15
1200
72 41 2.7 26 23 19 16 12 - - 37 2.9 25 21 18 14 11 - -
67 37 2.7 33 30 26 23 19 16 12 33 2.8 31 28 24 21 17 14 10
62 32 2.7 32 32 32 29 25 22 18 29 2.9 29 29 29 25 22 18 15
57 32 2.7 32 32 32 29 25 22 18 29 2.9 29 29 30 26 23 19 16
1350
72 41 2.7 28 24 20 16 12 - - 37 3.0 27 23 19 15 11 - -
67 37 2.7 35 31 27 23 19 15 11 33 2.9 32 29 25 21 17 13 9
62 32 2.7 32 32 32 28 24 20 16 29 2.9 29 29 29 25 21 17 13
57 33 2.7 33 33 33 29 25 21 17 29 2.9 29 29 30 26 22 18 14
1500
72 42 2.7 30 26 21 17 12 - - 37 3.1 28 24 20 15 11 - -
67 38 2.7 38 33 29 24 20 15 11 33 2.9 33 31 27 22 18 13 9
62 33 2.7 33 33 33 28 24 19 15 29 3.0 29 29 29 24 20 15 11
57 33 2.7 33 33 33 29 24 20 15 29 3.0 29 29 29 25 20 16 11
115°F 125°F
900
72 32 3.3 18 16 13 11 8 - - 28 3.7 17 14 12 9 7 - -
67 27 3.1232118161311 8 24 3.32219171411 9 6
62 24 3.2 24 23 21 18 16 13 11 21 3.5 21 20 18 15 13 10 8
57 25 3.2 25 25 23 20 17 15 12 22 3.5 22 22 20 18 15 13 10
1050
72 32 3.3 21 18 15 12 9 - - 29 3.5 19 16 13 10 7 - -
67 28 3.0262320171411 8 24 3.22422181512 9 6
62 25 3.1 25 24 23 20 17 14 11 21 3.4 21 21 20 17 14 11 8
57 25 3.1 25 25 25 22 19 16 13 22 3.4 22 22 22 19 16 13 10
1200
72 33 3.2 23 20 16 13 9 - - 29 3.4 21 18 14 11 7 - -
67 29 3.0292622191512 8 25 3.1252420171310 6
62 25 3.1 25 25 25 22 18 15 11 22 3.3 22 22 22 18 15 11 8
57 26 3.1 26 26 27 24 20 17 13 22 3.3 22 22 22 21 18 14 11
1350
72 33 3.3 25 21 17 13 9 - - 29 3.6 23 19 15 11 7 - -
67 29 3.1292723191511 8 24 3.2242421171310 6
62 25 3.2252525211713 9 21 3.42121211713 9 5
57 26 3.2 26 26 26 22 18 14 10 22 3.4 22 22 22 19 15 11 7
1500
72 33 3.4 27 22 18 13 9 - - 28 3.8 25 20 16 11 7 - -
67 28 3.2282825201611 7 24 3.42424231814 9 5
62 25 3.3252525201611 7 21 3.62121211612 7 3
57 25 3.3252525211612 8 22 3.62222221713 8 4
1. The capacities are gross ratings. For net capacity, deduct indoor blower motor, MBH=3.415 x kW. Refer to the appropriate Blower Perfor-
mance table for the kW of the supply air blower motor.
2. These ratings include the condenser fan motors (total 1 kW) and the compressor motors but not the supply air blower motor.
