Multipliers for determining the performance with other indoor sections.
NOTE: For dry bulb temperatures different than those listed (between 73-87 F), sensible capacity increases by 1060 BTUH per 1000 CFM per degree above the
listed temperature and decreases by 1060 BTUH per 1000 CFM per degree belowthe listed temperature.
COOLING PERFORMANCE DATA
AIR CONDITIONER MODEL NO. H1RA060S(25,46)
INDOOR COIL MODEL NO. G2FD060S24A
CONDENSER
ENTERING AIR
TEMPERATURE
ID CFM 1450 1700 1950
ID DB (°F) 85 80 70 85 80 70 85 80 70
ID WB (°F) 72 67 57 72 67 57 72 67 57
75
T.C. 61.2 58.5 56.3 61.8 59.1 56.9 62.3 59.6 57.5
S.C. 37.6 37.4 37.1 40.1 39.9 39.5 42.5 42.3 41.8
K.W 4.66 4.57 4.51 4.67 4.58 4.53 4.68 4.58 4.55
85
T.C. 60.6 58.0 55.0 61.2 58.6 55.8 61.9 59.3 56.7
S.C. 37.6 37.3 36.5 40.2 39.9 39.1 42.8 42.5 41.7
K.W 5.26 5.13 5.08 5.27 5.14 5.10 5.28 5.15 5.11
95
T.C. 60.0 57.4 53.7 60.7 58.5 54.8 61.4 59.0 55.8
S.C. 37.5 37.1 35.9 40.3 39.8 38.8 43.1 42.6 41.6
K.W 5.86 5.70 5.65 5.87 5.71 5.67 5.88 5.72 5.68
105
T.C. 58.1 54.6 50.0 58.9 55.7 51.3 59.7 56.8 52.7
S.C. 36.9 36.0 34.4 39.8 39.0 37.3 42.7 41.9 40.2
K.W 6.54 6.39 6.29 6.56 6.42 6.30 6.57 6.45 6.32
115
T.C. 56.2 51.8 46.3 57.1 53.2 47.9 57.9 54.5 49.5
S.C. 36.2 34.9 32.9 39.3 38.1 35.9 42.3 41.2 38.8
K.W 7.23 7.07 6.92 7.25 7.12 6.94 7.26 7.17 6.97
125
T.C. 54.3 49.0 42.6 55.2 50.6 44.5 56.2 52.3 46.4
S.C. 35.6 33.8 31.4 38.7 37.2 34.4 41.9 40.5 37.4
K.W 7.92 7.76 7.55 7.94 7.83 7.58 7.96 7.90 7.62
Air Handler Coil
T.C. S.C. KW
N1AHD2046 G2FD060(S,H)24 1.00 1.00 1.00
F2FP060 1.00 1.00 1.05
G1FA060S21,24 1.00 1.00 1.00
G1NA060S24T 0.98 0.98 1.01
G1UA060S21,24 1.00 1.00 1.00
