To eliminate erratic operation, seal the hole in the wall at the
thermostat with permagum or equivalent to prevent air drafts
affecting the anticipators in the thermostat.
Route the control wiring into the outdoor unit through the hole
provided. Connect the control wiring, per Figure 8.
EVACUATION
It will be necessary to evacuate the system if the unit has
developed a leak during shipment or was, for any other reason,
opened to the atmosphere. If a leak is suspected, leak test to
locate the leak. Repair the leak and test again.
WARNING:Never attempt to repair any brazed connections
while the system is under pressure. Personal injury
could result.
Evacuate the system down to at least 1,000 microns.
To verify if the system has no leaks, simply close the valve to
the vacuum pump suction to isolate the pump and hold the
system under vacuum. Watch the micron gauge for a few
minutes. If the micron gauge indicates a steady and continuous
rise, it’s an indication of a leak.
If the gauge shows a rise, then levels off after a few minutes
and remains fairly constant, its an indication the system is leak
free, but still contains moisture and may require further evacu-
ation if the reading is above 1000 microns.
OUTDOOR UNIT H2DH024 H2DH030 H2DH036 H2DH042 H2DH048 H2DH060
UNIT ORIFICE(S)** 61,63 65 75,78 78,81,84 90,93 93, 96
FACTORY R-22
CHARGE,LBS. OZ.
SWEAT 5 - 7 5 - 0 7 - 12 8 - 0 11 - 14 13 - 0
INDOOR COIL
COIL
ORIFICE*
REQUIRED SYSTEM ORIFICE + ADDITIONAL CHARGE, OZ.
G3HC / G1FC024 61 61 + 10 - - - - -
G3HC / G1FC030 69 61 + 23 65+25 - - - -
G3HC / G1FC036 81 - 65+28 78 + 3 - - -
G3HC / G1FC042 78 - - 78 + 8 81 + 16 - -
G3HC / G1FC048 90 - - - 81 + 7 90 + 13 -
G3HC / G1FC060 96 - - - - 90 + 25 96 + 4
G3UA024 59 63 + 0 - - - - -
G3UA030 65 63 + 2 65+16 - - - -
G3UA036 69 63 + 13 65+32 75 + 9 - - -
G3UA037 69 63 + 13 65+32 75 + 9 - - -
G3UA048 87 - - 78 + 17 81 + 16 90 + 14 -
G3UA060 96 - - - 84 + 21 90 + 38 96 + 25
G3UA061 96 - - - 84 + 21 90 + 29 96 + 25
G2UT048 - - - - + 16 - -
M3CF032 59 61 + 7 65+0 - - - -
M3CF044 69 - 65+0 78 + 2 78 + 3 - -
M3CF052 84 - - - - 90 + 10 -
G3CN030 65 63 + 2 65+16 - - - -
G3CN042 73 - - 78 + 8 81 + 7 - -
G3CN060 87 - - - - 93 + 24 -
M3HD024 59 61 + 6 - - - - -
M3HD036 69 61 + 9 65+15 78 + 0 - - -
M3HD048 84 - - 78 + 3 81 + 0 90 + 0 -
M3HD060 96 - - - - 90 + 28 93 + 16
M3UF024 53 (59) + 2 - - - - -
M3UF032 59 61 + 7 65+19 - - - -
M3UF044 69 61 + 14 65+22 73 + 3 78 + 5 - -
M3UF052 84 - - (81) + 9 81 + 1 93 + 0 -
M3UF064 90 - - - - - 93 + 16
F1SA / F1SF024 61 61 + 2 - - -
F1SA / F1SF030 67 61 + 4 - - -
F1SA / F1SF036 81 - - 78 + 3 -
* These orifices are factory-mounted in the flow control device of each indoor coil.
**These orfices are packed in the instruction/warranty packet of each outdoor unit.
NOTE: If orifice required is
not supplied
in coil or in the outdoor unit instruction packet, the orifice in ( ) must be ordered from the
Parts Department.
NOTE 2: Due to scroll compressor, hard start components are not required when using coils with TXV or Solenoid Valve kits.
TABLE 2 - ORIFICE SIZES & CHARGE ADD STANDARD COILS
550.36-N2Y
6 Unitary Products Group
