Subject to change without notice. Published in U.S.A. 813517-YTG-E-0114
Copyright © 2014 by Johnson Controls, Inc. All rights reserved. Supersedes: 813517-YTG-D-0813
York International Corp.
5005 York Drive
Norman, OK 73069
COIL - HD
1-3/4
D
5-5/8
A
B
C
3-3/4
2-5/8
1-3/8
OPENING
FOR
VAPOR
CONN.
OPENING
FOR
LIQUID
CONN.
OPENING
FOR
3/4 NPT
SECONDARY
DRAIN CONN.
OPENING
FOR
3/4 NPT
PRIMARY
DRAIN CONN.
7/8
1-7/8
4-1/8
1-3/8
OUTLET SAME
SIZE AS INLET
(3/4” FLANGE)
DIMENSIONS - HD Coils
Models
Dimensions
1
Refrigerant Connections
2
Height Width Opening Widths Line Size
ABCDLiquid Vapor
HD24S 24 28-3/4 21-5/8 23-3/4
3/8
3/4
HD36S 28 28-3/4 25-5/8 23-3/4
7/8HD48S 28 34-3/4 25-5/8 29-3/4
HD60S 30 34-3/4 27-5/8 29-3/4
1 All dimensions are in inches.
2 Refrigerant line sizes may require larger lines for extended line lengths. See Application Data part number 247077.
